Page 7-16 Xerox WorkCentre 4118 System Administration Guide
Network Installation Using Internet Services
LPR/LPD
Use these instructions to enable or disable LPR/LPD using CentreWare Internet Services.
Installation Procedure
There are two stages required to install the device on a LPR/LPD network using CentreWare
Internet Services:
¾ Configure the WorkCentre 4118
This procedure explains how to use CentreWare Internet Services to
configure the device.
¾ Test Print
A print job should be submitted to ensure the device has been installed and
configured correctly.
Configure the WorkCentre 4118
To complete the installation of the device, perform these steps:
¾ Enable CentreWare Internet Services (see “Enabling Internet Services” on page 7-5).
¾ At the CentreWare Internet Services Home Page for the WorkCentre 4118, select the
[Properties] tab.
¾ Select the plus symbol [+] to the left of the Connectivity folder in the Properties frame, and
then select the [+] symbol to the left of the Protocols folder.
¾ In the Properties frame, within the Protocols folder, select [LPR/LPD].
¾ Select the checkbox to enable LPR/LPD.
Enter the [Port Number].
NOTE: While you can change the port number at which the WorkCentre 4118 will
accept LPR print jobs, it is recommended that you do this ONLY with extreme
caution as most LPR spoolers are set to send print jobs to the default port number,
515.
¾ Click the [Apply] button to implement any changes.
1
2
3
4
5
6
