PA Unit

Parts List

REF. DESCRIPTION VALUE V/W TOL. MFR’S DESIG VXSTD P/N VERS. LOT.

LAY ADR

6N-5

PCB with Components CS1766001

Printed Circuit Board F3183000A 1-

C 6101 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6102 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6103 CERAMIC CAP. 0.0033uF 50V B DD107B332K50 K10176332 1-

C 6104 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6107 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6109 CERAMIC CAP. 0.01uF 50V F DD106F103Z50 K13179008 1-

C 6110 CERAMIC CAP. 470pF 50V SL DD109SL471J50 K00175471 1-

C 6111 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6112 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6116 CERAMIC CAP. 0.001uF 50V XB CD050XB102K50 K10179014 1-

C 6117 CERAMIC CAP. 0.0068uF 500V XB CD130XB682K500 K10276682 1-

C 6118 CERAMIC CAP. 0.0068uF 500V XB CD130XB682K500 K10276682 1-

C 6119 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6121 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6123 CERAMIC CAP. 220pF 500V SL DD12SL221J500 K00275221 1-

C 6124 CERAMIC CAP. 220pF 500V SL DD12SL221J500 K00275221 1-

C 6125 MICA CAP. 0.0012uF 500V DM19D122J5 K30279095 1-

C 6127 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6128 AL.ELECTRO.CAP. 10uF 16V RE2-16V100MMA 10UF K40129004 1-

C 6129 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6130 AL.ELECTRO.CAP. 10uF 16V RE2-16V100MMA 10UF K40129004 1-

C 6131 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6132 AL.ELECTRO.CAP. 10uF 16V RE2-16V100MMA 10UF K40129004 1-

C 6133 AL.ELECTRO.CAP. 1000uF 16V RE3-16V102MH3 1000UF K40129096 1-

C 6134 CERAMIC CAP. 0.1uF 25V X UAT10X104K-L45AE K19149025 1-

C 6135 AL.ELECTRO.CAP. 10uF 16V RE2-16V100MMA 10UF K40129004 1-

C 6136 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6137 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6138 AL.ELECTRO.CAP. 10uF 16V RE2-16V100MMA 10UF K40129004 1-

C 6139 AL.ELECTRO.CAP. 1uF 50V RE2-50V010M 1UF K40179055 1-

C 6140 AL.ELECTRO.CAP. 1uF 50V RE2-50V010M 1UF K40179055 1-

C 6141 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6142 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6143 CERAMIC CAP. 0.047uF 50V F DD110F473Z50 K13179009 1-

C 6145 CERAMIC CAP. 0.01uF 50V F DD106F103Z50 K13179008 1-

C 6146 FILM CAP. 0.1uF 100V ECQ-B1104JF K50205104 1-

C 6152 CERAMIC CAP. 47pF 50V CH DD106-979CH470J50 K26170195 1-

C 6153 CERAMIC CAP. 0.0047uF 50V B CK45B1H472MYS K10179025 1-

C 6154 CERAMIC CAP. 0.0047uF 50V B CK45B1H472MYS K10179025 1-

C 6155 MICA CAP. 750pF 500V LCQ18751K5 K30276751 1-

C 6157 CERAMIC CAP. 0.047uF 50V F UP050F473Z-A-B K28179002 1-

C 6158 CERAMIC CAP. 120pF 500V SL DD10SL121J500 K00275121 1-

C 6159 CERAMIC CAP. 0.0068uF 500V XB CD130XB682K500 K10276682 1-

C 6160 CERAMIC CAP. 0.0068uF 500V XB CD130XB682K500 K10276682 1-

C 6161 AL.ELECTRO.CAP. 3.3uF 25V RC2-25V3R3M 3.3UF K40149015 1-

C 6162 CERAMIC CAP. 470pF 500V SL DD11-979SL471K500 K26270053 1-

C 6163 CERAMIC CAP. 470pF 500V SL DD11-979SL471K500 K26270053 1-

D 6102 DIODE 11ES1 G2090499 1-

D 6103 DIODE 11ES1 G2090499 1-

D 6104 DIODE 11ES1 G2090499 1-

D 6105 DIODE 11ES1 G2090499 1-

J 6101 CONNECTOR TMP-J01X-A2 P1090255 1-

J 6102 CONNECTOR TMP-J01X-A2 P1090255 1-

J 6103 CONNECTOR SC25-02WS P0090621 1-

J 6105 TERMINAL R0100970 1-

J 6106 TERMINAL R0100970 1-

JP6101 WIRE ASSY A0393 T9206445 1-

L 6101 M.RFC 1.5uH LAL03VB1R5M L1790130 1-

L 6102 RFC A1 43T0.16 4X9CB-20 L1020666A 1-

L 6103 RFC WITH BEADS FB-43-5111 L1020015 1-

L 6104 TOROIDAL COIL 41uH 41.00U 3A FR9.5°5 L0021432 1-

L 6106 M.RFC 39uH LAL03VB390K L1790147 1-

Q 6101 TRANSISTOR 2SC2166 G3321660 1-

Q 6102 TRANSISTOR 2SC3133-21 G3090086 1-

Q 6103 TRANSISTOR 2SC3133-21 G3090086 1-

Q 6104 TRANSISTOR 2SC2879 G3328790 1-

Frequency Range RX	100 kHz - 30 MHz
Receiver Type	Double conversion superheterodyne
Antenna Impedance	50 ohms
Weight	15 kg
Voltage	13.8 VDC
Modes	AM, FM, SSB, CW, FSK
Current Drain TX	22 A
Receiver Sensitivity	0.16 μV (SSB, CW)
Frequency Range TX	160, 80, 40, 30, 20, 17, 15, 12, 10 m
