TUNER-CNTL Unit

Parts List

REF. DESCRIPTION VALUE V/W TOL. MFR’S DESIG VXSTD P/N VERS. LOT.

LAY ADR

6P-5

PCB with Components CB2088001

Printed Circuit Board F3247000B 1-

C 6501 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6502 CHIP CAP. 220pF 50V CH GRM40CH221J50PT K22170243 1-

C 6503 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6504 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6505 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6506 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6507 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6508 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 6509 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6510 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6511 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6512 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6513 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 6514 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6515 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6516 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6517 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 6518 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6519 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1-

C 6520 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6521 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6522 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6523 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6524 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6525 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6526 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6527 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6528 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 6529 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 6530 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6531 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 6532 CHIP TA.CAP. 1uF 16V TESVA1C105M1-8R K78120009 1-

C 6533 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6534 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6535 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6536 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6537 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6538 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6539 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6540 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6541 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6542 AL.ELECTRO.CAP. 100uF 10V RC2-10V101M(6X7) K40109015 1-

C 6543 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 6544 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6545 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 6546 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6547 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1-

C 6548 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1-

C 6549 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1-

C 6550 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6551 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6552 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6553 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6554 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6555 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6556 CHIP CAP. 0.0022uF 50V B GRM40B222M50PT K22170809 1-

C 6557 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6558 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6559 CHIP TA.CAP. 0.47uF 25V TESVA1E474M1-8R K78140009 1-

C 6560 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6561 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6562 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6563 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6564 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6565 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 6566 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

Frequency Range RX	100 kHz - 30 MHz
Receiver Type	Double conversion superheterodyne
Antenna Impedance	50 ohms
Weight	15 kg
Voltage	13.8 VDC
Modes	AM, FM, SSB, CW, FSK
Current Drain TX	22 A
Receiver Sensitivity	0.16 μV (SSB, CW)
Frequency Range TX	160, 80, 40, 30, 20, 17, 15, 12, 10 m
