ENC-A, MIC, HP Unit

Parts List

REF. DESCRIPTION VALUE V/W TOL. MFR’S DESIG VXSTD P/N VERS. LOT.

LAY ADR

6a-3

*** ENC-A UNIT ***

PCB with Components CB2064001

Printed Circuit Board FR0063200 1-

C 9402 CHIP CAP. 0.0047uF 50V B GRM40B472M50PT K22170813 1-

C 9403 CHIP CAP. 0.0047uF 50V B GRM40B472M50PT K22170813 1-

J 9401 CONNECTOR SB20-04WS P0090611 1-

J 9402 CONNECTOR SB20-05WS P0090612 1-

J 9403 CONNECTOR SB20-03WS P0090610 1-

J 9404 CONNECTOR SB20-04WS P0090611 1-

R 9401 CHIP RES. 0 1/8W 5% RMC1/8T 000J J24215000 1-

R 9403 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1-

R 9404 CHIP RES. 0 1/8W 5% RMC1/8T 000J J24215000 1-

R 9405 CHIP RES. 220 1/10W 5% RMC1/10T 221J J24205221 1-

R 9407 CHIP RES. 0 1/8W 5% RMC1/8T 000J J24215000 1-

R 9408 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1-

R 9409

CARBON FILM RES.

1k 1/6W 5% RD16TPJ102 1K J07225102 1-

R 9410

CARBON FILM RES.

1k 1/6W 5% RD16TPJ102 1K J07225102 1-

S 9401

ROTARY ENCODER

EC11B15242 Q9000623 1-

VR9401 POT. RK09L1120C04 10KB J60800251 1-

*** MIC UNIT ***

PCB with Components CB2073001

Printed Circuit Board F3525103

C 9421 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

J 9421 CONNECTOR FM214-8SMPT-NI P0091074 1-

JP9421 WIRE ASSY A0393 T9206486 1-

*** HP UNIT ***

PCB with Components CB2065001

Printed Circuit Board FR0063400 1-

C 9441 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

C 9442 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

C 9443 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

C 9444 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

J 9441 CONNECTOR HSJ0917-01-140 P1090852 1-

J 9442 CONNECTOR HLJ2335-01-3010 P1090639 1-

JP9441 WIRE ASSY A0393 T9206476A 1-

R 9441 CHIP RES. 0 1/8W 5% RMC1/8T 000J J24215000 1-

R 9442 CHIP RES. 0 1/2W 5% RMC1/2 JPATE J24275000 1-

R 9443 CHIP RES. 0 1/2W 5% RMC1/2 JPATE J24275000 1-

R 9444 CHIP RES. 0 1/2W 5% RMC1/2 JPATE J24275000 1-

R 9445 CHIP RES. 0 1/8W 5% RMC1/8T 000J J24215000 1-

R 9446 CHIP RES. 0 1/8W 5% RMC1/8T 000J J24215000 1-
