DSP-D Unit

Parts List

REF. DESCRIPTION VALUE V/W TOL. MFR’S DESIG VXSTD P/N VERS. LOT.

LAY ADR

6S-3

PCB with Components CB2063001

Printed Circuit Board F3531102A 1-

C 7101 AL.ELECTRO.CAP. 100uF 16V 16V101M6X7TR2 K46120007 1-

C 7102 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7103 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7104 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7105 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7106 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7107 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7108 AL.ELECTRO.CAP. 100uF 16V 16V101M6X7TR2 K46120007 1-

C 7109 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7110 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7111 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 7112 AL.ELECTRO.CAP. 100uF 16V 16V101M6X7TR2 K46120007 1-

C 7113 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7114 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7115 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 7116 CHIP CAP. 10pF 50V CH GRM40CH100D50PT K22170211 1-

C 7117 CHIP CAP. 10pF 50V CH GRM40CH100D50PT K22170211 1-

C 7118 CHIP CAP. 10pF 50V CH GRM40CH100D50PT K22170211 1-

C 7119 CHIP CAP. 10pF 50V CH GRM40CH100D50PT K22170211 1-

C 7120 CHIP CAP. 10pF 50V CH GRM40CH100D50PT K22170211 1-

C 7121 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

J 7101 CONNECTOR SC25-06WL P0090639 1-

J 7102 CONNECTOR SC25-04WL P0090713 1-

J 7103 CONNECTOR 12FMZ-BT P1090901 1-

Q 7101 IC UPD77016GM-KMD G1092034 1-

Q 7102 IC TC74HC4040AF TP2 G1091457 1-

Q 7103 IC TC74HC161AF TP2 G1091227 1-

Q 7104 IC RZT200P G1092041 1-

Q 7105 IC TC74HC595AF(EL) G1092039 1-

Q 7106 IC TC74HC595AF(EL) G1092039 1-

Q 7107 IC TC74HC14AF(EL) G1092038 1-

Q 7108 IC TC7S86F TE85R G1092040 1-

Q 7109 IC TC7S04F TE85R G1091444 1-

Q 7110 IC TC7S86F TE85R G1092040 1-

Q 7111 TRANSISTOR 2SC1623-T2BL6 G3316237F 1-

Q 7112 IC M27C1024-12F1 R0112 G1092579 1-

QS7101 IC SOCKET XR2A-4011-N P3090087 1-

R 7101 CHIP RES. 10k 1/10W 5% RMC1/10T 103J J24205103 1-

R 7102 CHIP RES. 10k 1/10W 5% RMC1/10T 103J J24205103 1-

R 7103 CHIP RES. 10k 1/10W 5% RMC1/10T 103J J24205103 1-

R 7104 CHIP RES. 2.7k 1/10W 5% RMC1/10T 272J J24205272 1-

R 7105 CHIP RES. 2.7k 1/10W 5% RMC1/10T 272J J24205272 1-

R 7106 CHIP RES. 2.7k 1/10W 5% RMC1/10T 272J J24205272 1-

R 7107 CHIP RES. 2.7k 1/10W 5% RMC1/10T 272J J24205272 1-

R 7108 CHIP RES. 2.7k 1/10W 5% RMC1/10T 272J J24205272 1-

R 7109 CHIP RES. 100k 1/10W 5% RMC1/10T 104J J24205104 1-

R 7110 CHIP RES. 680 1/10W 5% RMC1/10T 681J J24205681 1-

R 7111 CHIP RES. 10k 1/10W 5% RMC1/10T 103J J24205103 1-

R 7112 CHIP RES. 10k 1/10W 5% RMC1/10T 103J J24205103 1-

R 7113 CHIP RES. 2.2k 1/10W 5% RMC1/10T 222J J24205222 1-

T 7101 COIL 07WIDE TR6-3-2 L0021484 1-

X 7101 XTAL OSC

66.666MHz

NTO-764DC-66.666MHZ H9500270 1-
