SW-A, B, C, D, E Unit

Parts List

REF. DESCRIPTION VALUE V/W TOL. MFR’S DESIG VXSTD P/N VERS. LOT.

LAY ADR

6Y-3

*** SW-A UNIT ***

PCB with Components CB2083001

Printed Circuit Board F3525102 1-

JP9201 WIRE ASSY A0393 T9206474 1-

S 9201 TACT SWITCH SKQCAE N5090072 1-

S 9202 TACT SWITCH SKQCAE N5090072 1-

S 9203 TACT SWITCH SKQCAE N5090072 1-

*** SW-B UNIT ***

PCB with Components CB2084001

Printed Circuit Board FR0058700 1-

JP9221 WIRE ASSY AH006H T9206856A 1-

R 9221 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1-

S 9221

ROTARY ENCODER

EC16B241040PA Q9000641 1-

S 9222 TACT SWITCH SKHQFM N5090083 1-

S 9223 TACT SWITCH SKQCAE N5090072 1-

S 9224 TACT SWITCH SKQCAE N5090072 1-

S 9225 TACT SWITCH SKQCAE N5090072 1-

*** SW-C UNIT ***

PCB with Components CB2085001

Printed Circuit Board FR0058800 1-

JP9241 WIRE ASSY AH006H T9206853 1-

JP9242 WIRE ASSY AH006H T9206857 1-

R 9241

CARBON FILM RES.

220 1/6W 5% RD16PJ221 220 J01225221 1-

S 9241 TACT SWITCH SKQCAE N5090072 1-

S 9242 TACT SWITCH SKHQFM N5090083 1-

S 9243 LED GL8HD25 G2090638 1-

S 9244 TACT SWITCH SKHQFM N5090083 1-

S 9245 TACT SWITCH SKHQFM N5090083 1-

S 9246 TACT SWITCH SKHQFM N5090083 1-

*** SW-D UNIT ***

PCB with Components CB2086001

Printed Circuit Board FR0063000 1-

JP9261 WIRE ASSY A0393 T9206479 1-

S 9261 TACT SWITCH SKHQFM N5090083 1-

S 9262 TACT SWITCH SKHQFM N5090083 1-

*** SW-E UNIT ***

Printed Circuit Board FR0064600

P 8701 WIRE ASSY AH006H T9206911 1-

S 8701 TACT SWITCH SOT-154HST R66-5552 N5090114 1-

S 8702 TACT SWITCH SOT-154HST R66-5552 N5090114 1-
