Yaesu Mark-V FT-1000MP Field User Manual

PS Unit
Parts List
REF. DESCRIPTION VALUE V/W TOL. MFR’S DESIG VXSTD P/N VERS. LOT. LAY ADR
6d-3
B1 FERRITE BEADS B-20L-44 L9190120
B2 FERRITE BEADS B-20L-44 L9190120
B3 FERRITE BEADS B-20L-44 L9190120
B4 FERRITE BEADS B-20L-44 L9190120
C1 FILM CAP. 0.22uF 630V MMH224K630 K52280006
C2 CERAMIC CAP. 2200pF 250V DE2E3KH222MA3B K10249002
C3 CERAMIC CAP. 2200pF 250V DE2E3KH222MA3B K10249002
C7 FILM CAP. 0.022uF 50V AMZ223K50 K52170008
C8 AL.ELECTRO CAP. 820uF 200V SMQ200VSSN820M25B S8101201
C9 AL.ELECTRO CAP. 820uF 200V SMQ200VSSN820M25B S8101201
C10 FILM CAP. 0.47uF 400V ECQE4474KF K52260001
C11 CERAMIC CAP. 220pF 2KV DEHR33D221KC3B S8101202
C13 CERAMIC CAP. 220pF 2KV DEHR33D221KC3B S8101202
C14 AL.ELECTRO CAP. 27uF 50V EEUFC1H270 S8101203
C15 FILM CAP. 0.1uF 50V AMZ104K50 K52170009
C16 FILM CAP. 0.022uF 50V AMZ223K50 K52170008
C17 AL.ELECTRO CAP. 0.1uF 50V KME50VBR1M S8101204
C18 FILM CAP. 470pF 50V AMZ471K50 K52170010
C19 FILM CAP. 0.047uF 50V AMZ473K50 K52170011
C20 FILM CAP. 0.022uF 50V AMZ223K50 K52170008
C21 AL.ELECTRO CAP. 27uF 50V EEUFC1H270 S8101203
C30 FILM CAP. 1000pF 250V AMZ102K250 K52240005
C31 FILM CAP. 1000pF 250V AMZ102K250 K52240005
C32 AL.ELECTRO CAP. 2200uF 25V EEUFC1E222 K40129063
C33 AL.ELECTRO CAP. 2200uF 25V EEUFC1E222 K40129063
C34 AL.ELECTRO CAP. 2200uF 25V EEUFC1E222 K40129063
C36 FILM CAP. 0.1uF 630V MMC104K630 S8101205
C38 AL.ELECTRO CAP. 10uF 50V KME50VB10M S8101206
C40 CERAMIC CAP. 4700pF 50V DD107-63B472K50 S8101207
CN1 CONNECTOR 5045-03A P0090219
CX1 CERAMIC CAP. 1000pF 250V DE2E3KH102MA3B K12249001
CX2 CERAMIC CAP. 1000pF 250V DE2E3KH102MA3B K12249001
CX3 FILM CAP. 0.01uF 630V MMC103K630 K52280009
D1 DIODE S10VB60 G2090501
D3 DIODE RG2 G2090502
D5 DIODE RG2 G2090502
D6 DIODE RD56EB G2090503
D7 DIODE 1S953 G2009530
D8 DIODE 1S953 G2009530
D9 DIODE HZ22-1 G2090455
D10 DIODE 1SS270A G2090754
D11 DIODE ERA32-02 G2090505
D30 DIODE KSF30A20B S8101208
D31 DIODE KSF30A20B S8101208
D32 DIODE RD15EB2 G2090507
IC1 IC M51977P G1092375
IC2 REGULATOR NJM431L G1091276
L1 LINE FILTER SU10VD 20010 S8100251
L3 RFC HP104Z S8100205
L4 RFC FL1914A S8100252
LF1 LINE FILTER 736006 S8100201
PC1 PHOTO COUPLER PC817-X3 S8101209
PC2 PHOTO COUPLER PC817-X3 S8101209
Q1 TRIACK TM1041S-L G3090096
Q2 MOS FET 2SK1016-01 G3810160
Q3 MOS FET 2SK1016-01 G3810160
Q4 TRANSISTOR 2SC3705 G3337050
R1 FUSE RES. 10 1.6W A53K-100J S8101210
R2 CARBOM FILM RES. 1k 1/4W RD16S-1KW J01245102
R3 METAL FILM RES. 100 2W ERG2SJ-101 J22335101
R4 CARBOM FILM RES. 100k 1/2W ERD50TJ104 S8101211
R5 CARBOM FILM RES. 100k 1/2W ERD50TJ104 S8101211
R6 METAL FILM RES. 100k 1W ERG1SJ-104 J22309049
R7 RES. 0.05 5W MPC75-0.05W J31379002
R8 METAL FILM RES. 10 1W ERG1SJ-100 J22305100
R9 METAL FILM RES. 22 2W ERG2SJ-220 J22335220
R10 METAL FILM RES. 10 1W ERG1SJ-100 J22305100
R11 METAL FILM RES. 22 2W ERG2SJ-220 J22335220

Yaesu Mark-V FT-1000MP Field Specifications

General

Frequency Range RX	100 kHz - 30 MHz
Receiver Type	Double conversion superheterodyne
Antenna Impedance	50 ohms
Weight	15 kg
Voltage	13.8 VDC
Modes	AM, FM, SSB, CW, FSK
Current Drain TX	22 A
Receiver Sensitivity	0.16 μV (SSB, CW)
Frequency Range TX	160, 80, 40, 30, 20, 17, 15, 12, 10 m
