DSP-A Unit

Parts List

REF. DESCRIPTION VALUE V/W TOL. MFR’S DESIG VXSTD P/N VERS. LOT.

LAY ADR

6R-3

Parts List

PCB with Components CB2062001

Printed Circuit Board F3531101A 1-

C 7001 FILM CAP. 0.27uF 50V MMT0050J27400000000 K50170105 1-

C 7002 FILM CAP. 0.27uF 50V MMT0050J27400000000 K50170105 1-

C 7003 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 7004 FILM CAP. 0.27uF 50V MMT0050J27400000000 K50170105 1-

C 7005 FILM CAP. 0.27uF 50V MMT0050J27400000000 K50170105 1-

C 7006 FILM CAP. 0.27uF 50V MMT0050J27400000000 K50170105 1-

C 7007 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 7008 CHIP TA.CAP. 4.7uF 10V TEMSVA1A475M-8R K78100022 1-

C 7009 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 7010 CHIP CAP. 120pF 50V CH GRM40CH121J50PT K22170237 1-

C 7011 AL.ELECTRO.CAP. 10uF 16V RB2-16V100M-T2 K46120011 1-

C 7012 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7013 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7014 AL.ELECTRO.CAP. 10uF 16V RB2-16V100M-T2 K46120011 1-

C 7015 CHIP CAP. 0.0015uF 50V B GRM40B152M50PT K22170807 1-

C 7016 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7017 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7018 AL.ELECTRO.CAP. 10uF 16V RB2-16V100M-T2 K46120011 1-

C 7019 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

C 7020 AL.ELECTRO.CAP. 100uF 16V 16V101M6X7TR2 K46120007 1-

C 7021 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

C 7022 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 7023 CHIP TA.CAP. 4.7uF 10V TEMSVA1A475M-8R K78100022 1-

C 7024 AL.ELECTRO.CAP. 10uF 16V RB2-16V100M-T2 K46120011 1-

C 7025 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 7026 CHIP CAP. 120pF 50V CH GRM40CH121J50PT K22170237 1-

C 7027 AL.ELECTRO.CAP. 10uF 16V RB2-16V100M-T2 K46120011 1-

C 7028 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7029 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7030 AL.ELECTRO.CAP. 10uF 16V RB2-16V100M-T2 K46120011 1-

C 7031 CHIP CAP. 0.0015uF 50V B GRM40B152M50PT K22170807 1-

C 7032 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7033 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7034 AL.ELECTRO.CAP. 10uF 16V RB2-16V100M-T2 K46120011 1-

C 7035 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7036 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7037 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7038 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 7039 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7040 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 7041 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7042 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 7043 CHIP CAP. 330pF 50V CH GRM40CH331J50PT K22170247 1-

C 7044 CHIP CAP. 330pF 50V CH GRM40CH331J50PT K22170247 1-

C 7045 CHIP CAP. 470pF 50V CH GRM40CH471J50PT K22170251 1-

C 7046 CHIP CAP. 220pF 50V CH GRM40CH221J50PT K22170243 1-

C 7047 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7048 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7049 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7050 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7051 CHIP CAP. 330pF 50V CH GRM40CH331J50PT K22170247 1-

C 7052 CHIP CAP. 330pF 50V CH GRM40CH331J50PT K22170247 1-

C 7053 CHIP CAP. 0.0047uF 50V B GRM40B472M50PT K22170813 1-

C 7054 CHIP CAP. 0.0022uF 50V B GRM40B222M50PT K22170809 1-

C 7055 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7056 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7057 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7058 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7059 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

C 7060 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

C 7061 AL.ELECTRO.CAP. 100uF 16V 16V101M6X7TR2 K46120007 1-

C 7062 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7063 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7064 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 7065 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-

C 7066 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1-
