REG Unit

Parts List

REF. DESCRIPTION VALUE V/W TOL. MFR’S DESIG VXSTD P/N VERS. LOT.

LAY ADR

6X-5

P.C.B. with Components CB2076001

Printed Circuit Board FR0084900 1-

C 9001 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1-

C 9002 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1-

C 9003 AL.ELECTRO.CAP. 47uF 50V 50V470M6X11TR5 K46170024 1-

C 9004 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-

C 9005 AL.ELECTRO.CAP. 10uF 50V 50V100M5X11TR5 K46170021 1-

C 9006 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1-

C 9007 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1-

C 9008 AL.ELECTRO.CAP. 10uF 50V 50V100M5X11TR5 K46170021 1-

C 9009 AL.ELECTRO.CAP. 330uF 16V 16V331M8X11TR5 K46120002 1-

C 9010 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1-

C 9011 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1-

C 9012 AL.ELECTRO.CAP. 10uF 50V 50V100M5X11TR5 K46170021 1-

C 9013 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-

C 9014 AL.ELECTRO.CAP. 10uF 50V 50V100M5X11TR5 K46170021 1-

C 9015 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-

C 9016 AL.ELECTRO.CAP. 100uF 25V 25V101M6X11TR5 K46140005 1-

C 9017 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1-

C 9018 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-

C 9019 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-

C 9020 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-

C 9021 AL.ELECTRO.CAP. 2200uF 10V RE3-10V222M 2200UF K40109032 1-

C 9022 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1-

C 9023 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-

C 9024 AL.ELECTRO.CAP. 330uF 16V 16V331M8X11TR5 K46120002 1-

C 9025 AL.ELECTRO.CAP. 1uF 50V 50V010M4X7TR2 K46170030 1-

C 9026 CHIP CAP. 180pF 50V CH GRM39CH181J50PT K22174241 1-

C 9027 AL.ELECTRO.CAP. 330uF 16V 16V331M8X11TR5 K46120002 1-

C 9028 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1-

C 9029 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-

C 9030 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1-

C 9031 AL.ELECTRO.CAP. 330uF 16V 16V331M8X11TR5 K46120002 1-

C 9032 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1-

D 9001 DIODE DAN202K T146 G2070182 1-

D 9002 DIODE DAN202K T146 G2070182 1-

D 9003 DIODE 11EQS04-TA1B2 G2060008 1-

D 9004 SURGE ABSORBER ERZ-V10V681CS Q9000632 1-

J 9001 TERMINAL Y106 S5000179 1-

J 9002 TERMINAL Y106 S5000179 1-

J 9003 TERMINAL Y106 S5000179 1-

J 9004 TERMINAL Y106 S5000179 1-

J 9005 TERMINAL Y106 S5000179 1-

J 9006 TERMINAL Y106 S5000179 1-

J 9007 CONNECTOR SC25-02WS P0090621 1-

J 9008 CONNECTOR SC25-04WS P0090623 1-

J 9009 CONNECTOR SC25-07WS P0090626 1-

J 9010 CONNECTOR SC25-04WS P0090623 1-

J 9011 CONNECTOR SC25-04WS P0090623 1-

J 9012 CONNECTOR SC25-06WS P0090625 1-

J 9013 CONNECTOR SC25-05WS P0090624 1-

J 9014 CONNECTOR SC25-03WS P0090622 1-

J 9015 CONNECTOR SC25-02WS P0090621 1-

J 9016 CONNECTOR SC25-02WS P0090621 1-

J 9017 CONNECTOR SC25-02WS P0090621 1-

J 9018 CONNECTOR B2P3-VH P0090866 1-

J 9019 CONNECTOR B2P3-VH P0090866 1-

J 9020 CONNECTOR B2P3-VH P0090866 1-

L 9001 M.RFC 3.9mH RCR-875D-392K L1190383 1-

L 9002 M.RFC 1mH LAL03TA102K L1790119 1-

L 9003 M.RFC 1mH LAL03TA102K L1790119 1-

L 9004 M.RFC 3.9mH RCR-875D-392K L1190383 1-

Q 9001 IC HA17805P G1090936 1-

Q 9002 IC KIA7809PI G1092163 1-

Q 9003 TRANSISTOR PDTC144EE G3070244 1-

Q 9004 IC M5218AFP-600C G1091607 1-

Q 9005 TRANSISTOR 2SD1913R G3419130R 1-

Q 9006 TRANSISTOR 2SC2001-L G3320010L 1-
