IF Unit

Parts List

REF. DESCRIPTION VALUE V/W TOL. MFR’S DESIG VXSTD P/N VERS. LOT.

LAY ADR

6B-5

PCB with Components CB2067001

Prinred Circuit Board F3514000C 1

C 2001 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2004 AL.ELECTRO.CAP. 10uF 16V 16V100M4X7TR2 K46120004 1-

C 2005 AL.ELECTRO.CAP. 10uF 16V 16V100M4X7TR2 K46120004 1-

C 2006 AL.ELECTRO.CAP. 4.7uF 35V 35V4R7M4X7TR2 K46160004 1-

C 2007 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

C 2008 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2010 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2011 CHIP CAP. 100pF 50V CH GRM40CH101J50PT K22170235 1-

C 2012 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2013 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2015 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2016 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2017 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2018 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2019 CHIP CAP. 100pF 50V CH GRM40CH101J50PT K22170235 1-

C 2020 AL.ELECTRO.CAP. 1uF 50V 50V010M4X7TR2 K46170030 1-

C 2021 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2022 CHIP CAP. 0.047uF 50V B GRM40B473M50PT K22170823 1-

C 2023 AL.ELECTRO.CAP. 3.3uF 50V 50V3R3M4X7TR2 K46170032 1-

C 2024 CHIP CAP. 220pF 50V CH GRM40CH221J50PT K22170243 1-

C 2025 CHIP CAP. 220pF 50V CH GRM40CH221J50PT K22170243 1-

C 2026 CHIP CAP. 0.22uF 16V B GRM40B224M16PT K22120806 1-

C 2027 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2028 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2029 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2030 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2032 AL.ELECTRO.CAP. 3.3uF 50V 50V3R3M4X7TR2 K46170032 1-

C 2033 AL.ELECTRO.CAP. 10uF 16V 16V100M4X7TR2 K46120004 1-

C 2034 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2035 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2037 CHIP CAP. 220pF 50V CH GRM40CH221J50PT K22170243 1-

C 2038 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2039 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

C 2040 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

C 2041 CHIP CAP. 220pF 50V CH GRM40CH221J50PT K22170243 1-

C 2042 CHIP CAP. 100pF 50V CH GRM40CH101J50PT K22170235 1-

C 2043 CHIP CAP. 5pF 50V CH GRM40CH050C50PT K22170206 1-

C 2044 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2045 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2046 CHIP CAP. 0.0018uF 50V B GRM40B182M50PT K22170808 1-

C 2047 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2049 CHIP CAP. 0.0018uF 50V B GRM40B182M50PT K22170808 1-

C 2050 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2051 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2052 CHIP CAP. 47pF 50V CH GRM40CH470J50PT K22170227 1-

C 2053 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2054 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2055 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2056 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2057 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2058 CHIP CAP. 0.1uF 25V F GRM40F104Z25PT K22141005 1-

C 2059 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2060 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2061 CHIP CAP. 10pF 50V CH GRM40CH100D50PT K22170211 1-

C 2062 CHIP CAP. 100pF 50V CH GRM40CH101J50PT K22170235 1-

C 2063 FILM CAP. 0.001uF 50V ECQ-P1H102FZW K55179007 1-

C 2064 FILM CAP. 0.001uF 50V ECQ-P1H102FZW K55179007 1-

C 2065 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2066 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2067 CHIP CAP. 0.0018uF 50V B GRM40B182M50PT K22170808 1-

C 2068 CHIP CAP. 10pF 50V CH GRM40CH100D50PT K22170211 1-

C 2069 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2070 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2071 CHIP CAP. 0.0018uF 50V B GRM40B182M50PT K22170808 1-

C 2072 CHIP CAP. 10pF 50V CH GRM40CH100D50PT K22170211 1-

C 2073 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

Frequency Range RX	100 kHz - 30 MHz
Receiver Type	Double conversion superheterodyne
Antenna Impedance	50 ohms
Weight	15 kg
Voltage	13.8 VDC
Modes	AM, FM, SSB, CW, FSK
Current Drain TX	22 A
Receiver Sensitivity	0.16 μV (SSB, CW)
Frequency Range TX	160, 80, 40, 30, 20, 17, 15, 12, 10 m
