VR-A, B, C, D, E, F Unit

Parts List

REF. DESCRIPTION VALUE V/W TOL. MFR’S DESIG VXSTD P/N VERS. LOT.

LAY ADR

6Z-3

*** VR-A UNIT ***

PCB with Components CB2090001

Printed Circuit Board FR0062700 1-

JP9301 WIRE ASSY AH006H T9206867A 1-

JP9302 JUMPER WIRE A 0.8-5.0 Q6100003 1-

VR9301 POT.

RK097221003WA 10KB10KB

J62800126 1-

VR9302 POT.

RK097221003YA 10KB10KB

J62800127 1-

*** VR-B UNIT ***

PCB with Components CB2091001

Printed Circuit Board FR0058900 1-

R 9321 CHIP RES. 6.8k 1/10W 5% RMC1/10T 682J J24205682 1-

R 9322

CARBON FILM RES.

1k 1/6W 5% RD16TPJ102 1K J07225102 1-

R 9323

CARBON FILM RES.

10k 1/6W 5% RD16TPJ103 10K J07225103 1-

R 9324 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1-

R 9325 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1-

VR9321 POT. RK09711100WPA 10KB J60800208 1-

VR9322 POT. RK09711100WPA 10KB J60800208 1-

VR9323 POT. RK09711100WPA 10KB J60800208 1-

*** VR-C UNIT ***

PCB with Components CB2092001

Printed Circuit Board FR0059000 1-

JP9391 WIRE ASSY A0393 T9206487 1-

R 9391 CHIP RES. 10k 1/10W 5% RMC1/10T 103J J24205103 1-

VR9391 POT. RK09711100WPA 10KB J60800208 1-

*** VR-D UNIT ***

PCB with Components CB2093001

Printed Circuit Board FR0062800 1-

J 9361 CONNECTOR 12FMZ-ST P1090904 1-

J 9362 CONNECTOR SB20-03WL P0090843 1-

JP9361 WIRE ASSY AH006H T9206859 1-

JP9362 WIRE ASSY AH006H T9206858A 1-

JP9363 JUMPER WIRE A 0.8-5.0 Q6100003 1-

JP9364 JUMPER WIRE A 0.8-5.0 Q6100003 1-

JP9365 JUMPER WIRE A 0.8-7.5 Q6100004 1-

R 9361

CARBON FILM RES.

2.2k 1/6W 5% RD16UJ222 2.2K J02225222 1-

R 9362

CARBON FILM RES.

2.7k 1/6W 5% RD16UJ272 2.7K J02225272 1-

VR9361 POT. RK09711100WPA 10KB J60800208 1-

VR9362 POT. RK09711100WS0 10KC J60800209 1-

*** VR-E UNIT ***

PCB with Components CB2094001

Printed Circuit Board FR0063300 1-

J 9381 CONNECTOR SB20-03WL P0090843 1-

JP9381 WIRE ASSY AH013H T9206980 1-

R 9381 CHIP RES. 820 1/10W 5% RMC1/10T 821J J24205821 1-

R 9382 CHIP RES. 12k 1/10W 5% RMC1/10T 123J J24205123 1-

VR9381 POT. RK09L1120C04 10KB J60800251 1-

VR9382 POT. RK097111060U 10KB J60800252 1-

*** VR-F UNIT ***

PCB with Components CB2095001

Printed Circuit Board FR0062900 1-

JP9341 WIRE ASSY A0393 T9206478 1-

VR9341 POT. RK09711100WPA 10KB J60800208 1-

Questions and Answers:

Need help?

Do you have a question about the Yaesu Mark-V FT-1000MP Field and is the answer not in the manual?

Yaesu Mark-V FT-1000MP Field Specifications

General

Frequency Range RX	100 kHz - 30 MHz
Receiver Type	Double conversion superheterodyne
Antenna Impedance	50 ohms
Weight	15 kg
Voltage	13.8 VDC
Modes	AM, FM, SSB, CW, FSK
Current Drain TX	22 A
Receiver Sensitivity	0.16 μV (SSB, CW)
Frequency Range TX	160, 80, 40, 30, 20, 17, 15, 12, 10 m
