YASKAWA E-7 Series User Manual

3.2 Operating Procedures for Utility Functions
3.2.35 ZONE Table Edit/Save (FnB04)
3-114
3.2.35 ZONE Table Edit/Save (FnB04)
This function edits and saves ZONE tables. Saving a ZONE table to flash
memory after editing it ensures that the data will be retained even after
the control power has been turned off.
 Codes Displayed on the ZONE Table Editing
Screen
Refer to the following manual for information on interpreting the dis-
plays.
Σ-7-Series Σ-7S SERVOPACK Command Option Attachable Type with INDEXER
Module Product Manual (Manual No.: SIEP S800001 64)
Preparation
Always check the following before you edit or save a ZONE table.
• The parameters must not be write-prohibited (Fn010 must be set to
0000).
• A ZONE table save operation must not be in progress for any means
other than the digital operator.
Editing ZONE Tables
The operating procedure when setting ZONE N in ZONE number 5 is
explained here.
ZONE
Number
ZONE P ZONE N
0 ZP000 ZN000
1 ZP001 ZN001
… … …
31 ZP031 ZN031
Step Operation Result
1
Press the key to open the Utility
Function Mode main menu, and move
the cursor with the keys to
select FnB04.
2
Press the key to view the FnB04
operation screen.
Continued on next page.
㹀㹀ࠉࠉࠉࠉࠉ㹄㹓㹌㹁㹒㹇㹍㹌
㹄㹬㹀㸮㸱ࠉ㹎㹅㹋ࠉ㹃㹢㹧㹲
㹄㹬㹀㸮㸲ࠉ㹘㹍㹌㹃ࠉ㹃㹢㹧㹲
㹄㹬㹀㸮㸳ࠉ㹈㹑㹎㹂ࠉ㹃㹢㹧㹲
㹄㹬㹀㸮㸴ࠉ㹎㹅㹋ࠉ㹇㹬㹧㹲
㹀㹀ࠉࠉࠉࠉ㹘㹭㹬㹣㹃㹢㹧㹲
㹘㹎㸮㸮㸮㸻㸩㸮㸮㸮㸮㸮㸮㸮㸮
㹘㹎㸮㸮㸯㸻㸩㸮㸮㸮㸮㸮㸮㸮㸮
㹘㹎㸮㸮㸰㸻㸩㸮㸮㸮㸮㸮㸮㸮㸮
㹘㹎㸮㸮㸱㸻㸩㸮㸮㸮㸮㸮㸮㸮㸮
