1.7 Safety
Fig. 1-1: Programming pendant
WARNING!
Death or injury because of danger of crushing
If the emergency stop button does not function properly, the robot cannot be stopped in the
event of an emergency.
 The robot should not be used if the emergency stop button does not function.
 Before operating the manipulator check the emergency stop button. The SERVO power
must be deactivated immediately when the emergency stop button is pressed (see Fig.
1-3: "Emergency stop button") on the programming pendant.
 When the SERVO power is turned OFF, the "SERVO ON" LED (see Fig. 1-2: "LED
SERVO ON") on the programming pendant.
Fig. 1-2: LED SERVO ON
Fig. 1-3: Emergency stop button
Emergency stop button
