Yealink CP960 User Manual

Using the CP Wireless Expansion Mic CPW90
243
Using the CP Wireless Expansion Mic CPW90
This chapter provides basic operating instructions for the wireless expansion microphone
CPW90. Topics include:
 Placing the CPW90
 Turning the CPW90
 Registering/Unregistering the CPW90
 Muting or Unmuting the CPW90
 Idle Mode
 Viewing CPW90 Information
 Finding the CPW90
 Charging the CPW90
 CPW90 LED Instructions
 CPW90 Working Frequency
If you require additional information or assistance with the CPW90, contact your system
administrator.
Placing the CPW90
The CPW90 has a rubber pads on its base to prevent it from sliding. You can place the CPW90
on a conference table. Do the following to ensure optimal voice quality:
 The CPW90 should be less than 20 meters distant from the IP phone, and is not disturbed
by obstacles.
 Place the CPW90 on a stable surface and keep it away from obstacles so that it can
effectively pick up sounds.

Yealink CP960 Specifications

General

Control type	Touch
Display type	LCD
Product type	IP conference phone
Voice codecs	CNG, G.722, G.722.1C, G.723, G.726, OPUS, VAD, iLBC
Product color	Stainless steel
Frequency range	2400 - 5000 Hz
Display diagonal	5 \
Display resolution	720 x 1280 pixels
Phonebook capacity	1000 entries
Ethernet interface type	Fast Ethernet
Microphone direction type	Omnidirectional
Supports expansion microphones	Yes
USB connector type	Micro-USB B
RJ-11 ports quantity	1
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	338 mm
Height	74 mm
Package depth	392 mm
Package width	405 mm
Package height	141 mm
