Yealink CP960 User Manual

User Guide for CP960 IP Phone
28
Connect the Power and Wired Network
To connect the power and wired network:
1) Connect the Ethernet cable between the Internet port on the IP phone and PoE port on the
PoE adapter.
Note
Connect the CP Wired Expansion Mic CPE90
To connect the CP Wired Expansion Mic CPE90:
1. Connect the end of the CPE90 cable to one of the Mic ports on the phone.
Note
The IP phone should be used with Yealink original PoE adapter (54V/0.56A) only. The use of the
third-party PoE adapter may cause the damage to the phone. The cable and wire should be
replaced at once if its skin is broken.
Important! Do not remove power to the phone while it is updating firmware and configurations.
Up to two CPE90 can be connected to an IP phone. For more information on CPW90, refer to
Using the CP Wired Expansion Mic CPE90 on page 241.

Yealink CP960 Specifications

General

Control type	Touch
Display type	LCD
Product type	IP conference phone
Voice codecs	CNG, G.722, G.722.1C, G.723, G.726, OPUS, VAD, iLBC
Product color	Stainless steel
Frequency range	2400 - 5000 Hz
Display diagonal	5 \
Display resolution	720 x 1280 pixels
Phonebook capacity	1000 entries
Ethernet interface type	Fast Ethernet
Microphone direction type	Omnidirectional
Supports expansion microphones	Yes
USB connector type	Micro-USB B
RJ-11 ports quantity	1
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	338 mm
Height	74 mm
Package depth	392 mm
Package width	405 mm
Package height	141 mm
