| Getting Started | 39

Rear Panel of VCM34

Name Description

1 PoE Connect to the VC Hub/Phone port on the VCS

endpoint.

2 Internet It is used to connect VCM34.

Hardware of MSpeaker

Front Panel of MSpeaker
