Table B.2-2 Connections of Straight Through Power Supply Ethernet Cables (C-RJ45-001)
End A Signal Name Conductor Color End B Signal Name Conductor Color
1 Data receiving Rx+ White/orange 1 Data transmitting Tx+ White/orange
2 Data receiving Rx- Orange 2 Data transmitting Tx- Orange
3 Data transmitting Tx+ White/green 3 Data receiving Rx+ White/green
4 GND Blue 4 GND Blue
5 GND White/blue 5 GND White/blue
6 Data transmitting Tx- Green 6 Data receiving Rx- Green
7 -48V White/brown 7 -48V White/brown
8 -48V Brown 8 -48V Brown
Note:
These cables are with -48 V DC power supply, so make sure to prevent short circuits,
otherwise, the signal will be interrupted and the equipment may not work normally, and
even the equipment protection action will be activated. GND and -48 V each occupy
one twisted pair. These twisted pairs should be separate, otherwise short circuit may
occur.
B.2.3 Making of Crossover Ethernet Cables (RJ45J)
The connections of the crossover Ethernet cables are shown in Table B.2-3.
Table B.2-3 Connections of Crossover Ethernet Cables (RJ45J)
End A Signal Name Conductor Color End B Signal Name Conductor Color
1 Data receiving Rx+ White/orange 3 Data transmitting Tx+ White/green
2 Data receiving Rx- Orange 6 Data transmitting Tx- Green
3 Data transmitting Tx+ White/green 1 Data receiving Rx+ White/orange
4 MATCH1 Blue 4 MATCH1 Blue
5 MATCH2 White/blue 5 MATCH2 White/blue
6 Data transmitting Tx- Green 2 Data receiving Rx- Orange
7 MATCH3 White/brown 7 MATCH3 White/brown
8 MATCH4 Brown 8 MATCH4 Brown
