Parameter description:
Name Range Description
A.B.C.D IP address Addresses of Trap destination hosts
version 1~2 Trap version number
5.4.19 Command to Manage Telnet Idle Timeout
Command mode: Configure mode
Function: Set the automatic exit time when the Telnet window is idle
Command format: wlan (config) #telnet idle-timeout time-value
Parameter description:
Name Range Description
time-value 300~3600 (unit: s)
The automatic exit time when the Telnet window is
idle (300s by default)
5.4.20 Commands to Upload/download TFTP Files
1. tftp dir
Command mode: Configure mode
Function: Check the free space of a flash disk (unit: byte)
Command format: wlan (config) #tftp dir
2. tftp pic
Command mode: Configure mode
Function: Download graphics files from the Web configuration pages on the
TFTP server and save them to a flash disk.
Command format: wlan (config) #tftp pic A.B.C.D
Parameter description:
Name Range Description
A.B.C.D IP address IP Address of a TFTP server in dotted decimal format
3. Download files using tftp get
Command mode: Configure mode
Function: Download files from the TFTP server using TFTP and save them to

Zte ZXR10 Specifications

General

Product Series	ZXR10
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Switching Capacity	256 Gbps
Forwarding Performance	96 Mpps
Humidity	10% to 90% (non-condensing)
