ACH550-UH User’s Manual 1-277
Fieldbus adapter
Generic profile technical data
Overview
The generic profile aims to fulfill the industry-standard drive profile for each protocol
(e.g. PROFIdrive for PROFIBUS, AC/DC Drive for DeviceNet).
Control Word
As described earlier in Control interface the
CONTROL WORD is the principal means
for controlling the drive from a fieldbus system. For specific
CONTROL WORD content,
see the user’s manual provided with the FBA module.
Status Word
As described earlier in Control interface, the contents of the
STATUS WORD is status
information, sent by the drive to the master station. For specific
STATUS WORD
content, see the user’s manual provided with the FBA module.
Reference
As described earlier in Control interface, the
REFERENCE word is a speed or
frequency reference.
Note: REF2 is not supported by the Generic Drive profiles.
Reference scaling
REFERENCE scaling is fieldbus type specific. However, at the drive, the meaning of a
100%
REFERENCE value is fixed as described in the table below. For a detailed
description on the range and scaling of the
REFERENCE, see the user’s manual
supplied with the FBA module.
Generic Profile
Reference Range
Reference
Type
Scaling Remarks
REF Fieldbus
specific
Speed -100% = -(par. 9908)
0 = 0
+100 = (par. 9908)
Final reference limited by
1104/1105.
Actual motor speed limited by 2001/
2002 (speed).
Frequency -100% = -(par. 9907)
0 = 0
+100 = (par. 9907)
Final reference limited by
1104/1105.
Actual motor speed limited by 2007/
2008 (frequency).
