ACH550-PCR/PDR User’s Manual 3-25
Technical data
Dimensional references
The following tables contain dimensional references that identify the dimensional
information applying to a given type code.
208/240V drive with disconnect
1. “PxR” represents both PCR and PDR.
HP Type Code
1
AMP
Base
Drive
Frame
UL Type /
NEMA 1
Dim. Ref.
Page 3-28
(+B055)
UL Type /
NEMA 12
Dim. Ref.
Page 3-29
(+B058)
UL Type /
NEMA 3R
Dim. Ref.
Page 3-30
1
ACH550-PxR-04A6-2
4.6 R1 PX1-1 PX12-1 PX3R-1
1.5 ACH550-PxR-06A6-2 6.6 R1 PX1-1 PX12-1 PX3R-1
2
ACH550-PxR-07A5-2 7.5 R1 PX1-1 PX12-1 PX3R-1
3 ACH550-PxR-012A-4 11.8 R1 PX1-1 PX12-1 PX3R-1
5 ACH550-PxR-017A-2 16.7 R1 PX1-1 PX12-1 PX3R-1
7.5
ACH550-PxR-024A-2 24.2 R2 PX1-2 PX12-2 PX3R-2
10 ACH550-PxR-031A-2 30.8 R2 PX1-2 PX12-2 PX3R-3
15 ACH550-PxR-046A-2 46.2 R3 PX1-3 PX12-3 PX3R-3
20
ACH550-PxR-059A-2 59.4 R3 PX1-3 PX12-3 PX3R-3
25 ACH550-PxR-075A-2 74.8 R4 PX1-4 PX12-4 PX3R-4
30 ACH550-PxR-088A-2 88 R4 PX1-5 PX12-5 PX3R-5
40
ACH550-PxR-114A-2 114 R4 PX1-5 PX12-5 PX3R-5
50 ACH550-PxR-143A-2 143 R6 PX1-6 PX12-6 PX3R-6
60 ACH550-PxR-178A-2 178 R6 PX1-6 PX12-6 PX3R-6
75
ACH550-PxR-221A-2 221 R6 PX1-6 PX12-6 PX3R-6
100 ACH550-PxR-248A-2 248 R6 PX1-6 PX12-6 PX3R-6
