Parameters
Parameters
Complete parameter list
The following table lists all parameters. Table header abbreviations are:
•S
= Parameters can be modified only when the drive is stopped.
• User = Space to enter desired parameter values.
Code Name Range Resolution Default User S
Group 99: START-UP DATA
9901 LANGUAGE 0…16 1 0 (ENGLISH)
9902
APPLIC MACRO -3…15, 31 1 1 (HVAC DEFAULT) 
9904
MOTOR CTRL MODE 1, 3 1 3 (SCALAR:FREQ) 
9905 MOTOR NOM VOLT 115…345 V (200 V, US) 1 V 230 V (US) 
230…690 V (400 V, US) 460 V (US)
288…862 V (600 V, US) 575 V (US)
9906
MOTOR NOM CURR 0.15 · I
2n
… 1.5 · I
2n
0.1 A 1.0 · I
2n

9907
MOTOR NOM FREQ 10.0…500.0 Hz 0.1 Hz 60.0 Hz (US) 
9908
MOTOR NOM SPEED 50…30000 rpm 1 rpm Size dependent 
9909 MOTOR NOM POWER 0.15…1.5 · P
n
0.1 hp 1.0 · P
n

9910
ID RUN 0, 1 1 0 (OFF/IDMAGN) 
9915
MOTOR COSPHI 0.01…0.97 0.01 0 (IDENTIFIED) 
Group 01: OPERATING DATA
0101
SPEED & DIR -30000…30000 rpm 1 rpm -
0102
SPEED 0…30000 rpm 1 rpm -
0103 OUTPUT FREQ 0.0…500.0 Hz 0.1 Hz -
0104
CURRENT 0.0…1.5 · I
2n
0.1 A -
0105
TORQUE -200.0…200.0% 0.1% -
0106 POWER -1.5…1.5 · P
n
0.1 kW -
0107
DC BUS VOLTAGE 0…2.5 · V
dN
1V -
0109
OUTPUT VOLTAGE 0…2.0 · V
dN
1V -
0110
DRIVE TEMP 0.0…150.0 C0.1C-
0111
EXTERNAL REF 1 0.0…500.0 Hz / 0…30000 rpm 0.1 Hz / 1 rpm -
0112
EXTERNAL REF 2 0.0…100.0% (0.0…600.0% for torque) 0.1% -
0113
CTRL LOCATION 0…2 1 -
0114
RUN TIME (R) 0…9999 h 1 h -
0115
KWH COUNTER (R) 0…65535 kWh 1 kWh -
0116
APPL BLK OUTPUT 0.0…100.0% (0.0…600.0% for torque) 0.1% -
0118
DI 1-3 STATUS 000…111 (0…7 decimal) 1 -
0119 DI 4-6 STATUS 000…111 (0…7 decimal) 1 -
0120
AI 1 0.0…100.0% 0.1% -
0121
AI 2 0.0…100.0% 0.1% -
0122
RO 1-3 STATUS 000…111 (0…7 decimal) 1 -
