ACH550-PCR/PDR User’s Manual 3-19
Technical data
Technical data
Input power connections (supplement to ACH550-UH User’s Manual
Fuses
NOTE: Although fuses listed are similar in functional characteristics to fuses listed in
the ACH550-UH User’s Manual, physical characteristics may differ. Fuses from
other manufacturers can be used if they meet the functional characteristics of those
in these tables.
208/240 volt fuses
1. “PxR” represents both PCR and PDR.
2. UL Type / NEMA 3R enclosed units are provided with Bussman Type JJS or equivalent fuses. Fuse
ratings shown relate to latest production. Where installed product includes fuses of a lower rating, either
rating may be used.
208/240 Volt
Frame
Size
Drive Input Fuse Ratings
HP Type Code
1
Amps
(600V)
Bussmann
Type
1 ACH550-PDR-04A6-2 R1 15 KTK-R-15
1.5 ACH550-PDR-06A6-2 R1 15 KTK-R-15
2 ACH550-PDR-07A5-2 R1 15 KTK-R-15
3 ACH550-PDR-012A-2 R1 15 KTK-R-15
5 ACH550-PDR-017A-2 R1 30 KTK-R-30
7.5 ACH550-PDR-024A-2 R2 30 KTK-R-30
10 ACH550-PDR-031A-2 R2 60 JJS-60
15 ACH550-PDR-046A-2 R3 100 JJS-100
20 ACH550-PDR-059A-2 R3 100 JJS-100
25 ACH550-PDR-075A-2 R4 100 JJS-100
30 ACH550-PxR-088A-2 R4 200
170M1370
2
or 170M2617
40 ACH550-PxR-114A-2 R4 200
170M1370
2
or 170M2617
50 ACH550-PxR-143A-2 R6 200
170M1370
2
or 170M2617
60 ACH550-PxR-178A-2 R6 315
170M1372
2
or 170M2619
75 ACH550-PxR-221A-2 R6 315
170M1372
2
or 170M2619
100 ACH550-PxR-248A-2 R6 315
170M1372
2
or 170M2619
