Actual signals and parameters 185
DI2,3(INV) See selection DI1,2(INV).-8
DI3,4(INV) See selection DI1,2(INV).-9
DI4,5(INV) See selection DI1,2(INV).-10
DI1,2,3(INV) Constant speed selection through inverted digital inputs DI1,
DI2 and DI3. 1 = DI active, 0 = DI inactive.
-12
DI3,4,5(INV) See selection DI1,2,3(INV).-13
1202 CONST
SPEED 1
Defines constant speed (drive output frequency) 1. E: 5.0 Hz
U: 6.0 Hz
0.0…500.0 Hz Output frequency in Hz 1 = 0.1 Hz
1203 CONST
SPEED 2
Defines constant speed (drive output frequency) 2. E: 10.0 Hz
U: 12.0 Hz
0.0…500.0 Hz Output frequency in Hz 1 = 0.1 Hz
1204 CONST
SPEED 3
Defines constant speed (drive output frequency) 3. E: 15.0 Hz
U: 18.0 Hz
0.0…500.0 Hz Output frequency in Hz 1 = 0.1 Hz
1205 CONST
SPEED 4
Defines constant speed (drive output frequency) 4. E: 20.0 Hz
U: 24.0 Hz
0.0…500.0 Hz Output frequency in Hz 1 = 0.1 Hz
1206 CONST
SPEED 5
Defines constant speed (drive output frequency) 5. E: 25.0 Hz
U: 30.0 Hz
0.0…500.0 Hz Output frequency in Hz 1 = 0.1 Hz
1207 CONST
SPEED 6
Defines constant speed (drive output frequency) 6. E: 40.0 Hz
U: 48.0 Hz
0.0…500.0 Hz Output frequency in Hz 1 = 0.1 Hz
1208 CONST
SPEED 7
Defines constant speed (drive output frequency) 7.
Constant speed 7 is also used with fault functions (3001
AI<MIN FUNCTION, 3002 PANEL COMM ERR and 3018
COMM FAULT FUNC).
E: 50.0 Hz
U: 60.0 Hz
0.0…500.0 Hz Output frequency in Hz 1 = 0.1 Hz
All parameters
No. Name/Value Description Def/FbEq
DI DI2 DI3 Operation
1 1 1 No constant speed
0 1 1 Speed defined by par. 1202 CONST SPEED 1
1 0 1 Speed defined by par. 1203 CONST SPEED 2
0 0 1 Speed defined by par. 1204 CONST SPEED 3
1 1 0 Speed defined by par. 1205 CONST SPEED 4
0 1 0 Speed defined by par. 1206 CONST SPEED 5
1 0 0 Speed defined by par. 1207 CONST SPEED 6
0 0 0 Speed defined by par. 1208 CONST SPEED 7
