Actual signals and parameters 189
CONST FREQ A constant speed is in use. See parameter group 12
CONSTANT SPEEDS.
19
REF LOSS Reference or active control location is lost. 20
OVERCURRE
NT
Alarm/Fault by overcurrent protection function 21
OVERVOLTAG
E
Alarm/Fault by overvoltage protection function 22
DRIVE TEMP Alarm/Fault by drive overtemperature protection function 23
UNDERVOLTA
GE
Alarm/Fault by undervoltage protection function 24
AI1 LOSS Analog input AI1 signal is lost. 25
AI2 LOSS Analog input AI2 signal is lost. 26
MOTOR TEMP Alarm/Fault by motor overtemperature protection function.
See parameter 3005 MOT THERM PROT.
27
STALL Alarm/Fault by stall protection function. See parameter 3010
STALL FUNCTION.
28
PID SLEEP PID sleep function. See parameter group 40 PROCESS PID
SET 1 / 41 PROCESS PID SET 2.
30
PFC Start/stop motor in PFC control. See parameter group 81
PFC CONTROL. Use this option only when PFC control is
used. Selection activated/deactivated when the drive is not
running.
31
AUTOCHANG
E
PFC Autochange operation is performed. Use this option
only when PFC control is used.
32
FLUX READY Motor is magnetized and able to supply nominal torque. 33
USER MACRO
2
User macro 2 is active. 34
COMM Fieldbus control signal 0134 COMM RO WORD. 0 = de-
energize output, 1 = energize output.
35
All parameters
No. Name/Value Description Def/FbEq
0134
value
Binary RO4
(MREL)
RO3
(MREL)
RO2
(MREL)
DO RO1
0 00000 0 0 0 0 0
1 00001 0 0 0 0 1
2 00010 0 0 0 1 0
30001100011
4 00100 0 0 1 0 0
5…30 … … … … … …
31 11111 1 1 1 1 1
To Next Page
