190 Actual signals and parameters
COMM(-1) Fieldbus control signal 0134 COMM RO WORD. 0 = de-
energize output, 1 = energize output.
36
TIMED FUNC 1 Timed function 1 is active. See parameter group 36 TIMED
FUNCTIONS.
37
TIMED FUNC 2 Timed function 2 is active. See parameter group 36 TIMED
FUNCTIONS.
38
TIMED FUNC 3 Timed function 3 is active. See parameter group 36 TIMED
FUNCTIONS.
39
TIMED FUNC 4 Timed function 4 is active. See parameter group 36 TIMED
FUNCTIONS.
40
MNT TRIG FAN Cooling fan running time counter is triggered. See
parameter group 29 MAINTENANCE TRIG.
41
MNT TRIG
REV
Revolutions counter is triggered. See parameter group 29
MAINTENANCE TRIG.
42
MNT TRIG
RUN
Run time counter is triggered. See parameter group 29
MAINTENANCE TRIG.
43
MNT TRIG
MWH
MWh counter is triggered. See parameter group 29
MAINTENANCE TRIG.
44
START DELAY Start delay is active. 46
USER LOAD C Alarm/Fault from the user load curve. See parameter group
37 USER LOAD CURVE.
47
PIPE FILL Pipe fill (Precharge) function is active. See parameters
4421…4426.
53
PROFILE
HIGH
Actual signal 0116 APPL BLK OUTPUT, 0132 PID 1
DEVIATION or 0133 PID 2 DEVIATION has stayed over
limit 4419 PROFILE OUTP LIM longer than the time defined
by parameter 4420 PROF LIMIT ON DLY. See parameters
4418…4420.
54
INLET PROT Pump inlet protection function is active or has caused the
drive to trip. See parameters 4401…4408.
55
O
UTLET PROT Pump outlet protection function is active or has caused the
drive to trip. See parameters 4409…4416.
56
MOT. HEATING Energizes relay when motor heating is active. See
parameter 2115 MOT. HEATING SEL.
69
1402 RELAY
OUTPUT 2
See parameter 1401 RELAY OUTPUT 1. Available only if
the MREL relay output extension module is connected to
the drive.
NOT SEL
All parameters
No. Name/Value Description Def/FbEq
0134
value
Binary RO4
(MREL)
RO3
(MREL)
RO2
(MREL)
DO RO1
0 00000 1 1 1 1 1
1 00001 1 1 1 1 0
2 00010 1 1 1 0 1
300011 1 1 1 00
4 00100 1 1 0 1 1
5…30 … … … … … …
31 11111 0 0 0 0 0
