Technical data 127
Auxiliary circuit power consumption
Cabinet heater (option
+G300)
100 W
Materials
Cabinet Hot-dip zinc coated 1.5 mm thick steel sheet (thickness of coating approximately
20 micrometers). Polyester thermosetting powder coating (thickness
approximately 80 micrometers) on visible surfaces, color RAL 7035 and RAL
9017. PC/ABS 3 mm, color NCS 1502-Y (RAL 9002 / PMS 1C Cool Grey).
Busbars Tin-plated copper
Air filters of IP54 drives Inlet (door): airComp 300-50
288 mm x 521 mm (ABB code: 64640194)
688 mm x 521 mm (ABB code 64748017)
Outlet (roof): airTex G150
2 pcs: 398 mm x 312 mm (ABB code: 64722166)
Fire safety of materials
(IEC 60332-1)
Insulating materials and non-metallic items mostly self-extinctive
Package Standard package:
• timber, polyethylene sheet (thickness 0.2 mm), stretch film (thickness
0.023 mm), PP tape, PET strap, sheet metal (steel)
• for land and air transport when planned storage time is less than 2 months or
when storage can be arranged in clean and dry conditions less than 6 months
• can be used when products will not be exposed to corrosive atmosphere
during transport or storage
Container package:
• timber, VCI sheet film (PE, thickness 0.15 mm), VCI stretch film (PE,
thickness 0.04 mm), VCI emitter bags, PP tape, PET strap, sheet metal (steel)
• for sea transport in containers
• recommended for land and air transport when storage time prior to installation
exceeds 6 months or storage is arranged in partially weather-protected
conditions
Seaworthy package:
• timber, plywood, VCI sheet film (PE, thickness 0.15 mm), VCI stretch film (PE,
thickness 0.04 mm), VCI emitter bags, PP tape, PET strap, sheet metal (steel)
• for sea transport with or without containerization
• for long storage periods in environments where roofed and humidity-
controlled storage cannot be arranged
Cabinets are fastened to the pallet with screws and braced from the top end to
the package walls to prevents swaying inside the package. Package elements
are attached together with screws. For handling the packages, see section
Moving and unpacking the drive on page 41.
Disposal The main parts of the drive can be recycled to preserve natural resources and
energy. Product parts and materials should be dismantled and separated.
Generally all metals, such as steel, aluminum, copper and its alloys, and
precious metals can be recycled as material. Plastics, rubber, cardboard and
other packaging material can be used in energy recovery. Printed circuit boards
and DC capacitors (C1-1 to C1-x) need selective treatment according to
IEC 62635 guidelines. To aid recycling, plastic parts are marked with an
approppriate identification code.
Contact your local ABB distributor for further information on environmental
aspects and recycling instructions for professional recyclers. End of life
treatment must follow international and local regulations.
