3.3.6 Inspecting the cable harness
Location of cable harness
The figure shows the location of the cable harness.
xx0900000012
Bracket, lower armA
Cable harnessB
Hole in lower armC
Bracket, lower armD
Cable straps steel (One not visible here)E
Bracket, frameF
Cable strap plastic, lower armG
Bracket, armhouseH
Continues on next page
Product manual - IRB 2600 135
3HAC035504-001 Revision: AD
© Copyright 2009-2023 ABB. All rights reserved.
3 Maintenance
3.3.6 Inspecting the cable harness
