2.5 Installing options
2.5.1 Installation of cooling fan for motors (option)
General
A cooling fan can be installed on motor axis 1 and/or axis 2 for IRC5 robots.
Location of cooling fans
The fans are installed on the motors, axes 1 or 2, as shown in the figure below.
xx0900000232
Fan, motor axis 1A
Fan, motor axis 2B
Protection coverC
