ABB IRB 760 User Manual

Installation, mechanical stops axis 1
Use this procedure to fit mechanical stops to axis 1 of the robot. An assembly
drawing is also enclosed with the product.
NoteAction
DANGER
Turn off all:
• electric power supply to the robot
• hydraulic pressure supply to the robot
• air pressure supply to the robot
Before entering the robot working area.
1
Tightening torque: 120 Nm.Fit the additional mechanical stop to the
frame according to the figure Mechanical
stops, axis 1 on page 93.
2
The system parameters that must be
changed (Upper joint bound and Lower
joint bound) are described in Technical
reference manual - System parameters.
Adjust the software working range limitations
(system parameter configuration) to corres-
pond to the mechanical limitations.
3
WARNING
If the mechanical stop pin is deformed after
a hard collision, it must be replaced!
Deformed movable stops and/or additional
stops as well as deformed attachment
screws must also be replaced after a hard
collision.
4
94 3HAC039838-001 Revision: C
© Copyright 2013 ABB. All rights reserved.
2 Installation and commissioning
2.4.2 Mechanically restricting the working range of axis 1
Continued

ABB IRB 760 Specifications

General

Type	Industrial Robot
Model	IRB 760
Manufacturer	ABB
Degrees of Freedom	6
Axes	6
Protection Standard	IP67
Controller	IRC5
Protection	Dust and water-resistant
Mounting	Floor
Repeatability	±0.05 mm
