03 . INSTALLATION AND WIRING 13
Functions
Terminal no.
M10x 24VDC
X1:1
DI0
X1:2
DI1
X1:3
DI2
X1:4
DI3
X1:5
DI4
X1:6
DI5
X1:7
DI6
X1:8
DI7
X1:9
DI8
X1:10
DI9
X1:11
DI10
X1:12
DI11
X1:13
DI12
X1:14
DI_COM
Digital input common terminal
Digital input common terminal
—
Terminal block X1 Digital Inputs
Terminal block X1:1 ~10 is allocated for digital in-
puts (DI) wirings. Depending on voltage type,
there are 13 sets of DIs in M10x 24VDC type and 9
sets in 110/240VAC type. Actual function of DIs is
individually configurable.
M10x 110/240VAC
DI0
DI4
DI5
DI6
DI8
DI_COM
DI1
DI2
DI3
DI7
—
05 An example of using two sets of power supply
Wiring Tip:
As M10x measures the voltage drop through
DIs, any unnecessary voltage changes or dis-
turbance on DI circuit should be avoided.
e.g. if DIs are to be wired to a remote field
from the starter in a DC application, a sepa-
rate supply from the field may be consid-
ered. (Fig 05). If DIs are supplied by AC, an in-
terposing relay may be used to segregate
the interference from the field.
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
Configurable
