ABB M10 Series User Manual

Terminal no. Name Description
X4:12 GROUND Ground safety and surge
—

Terminal block X4 Ground terminal
This is an additional ground terminal provided
for dissipating transient signals and surges. It
must be connected by a thick wire or braid to
the system ground for reliable operation.
Terminal no. Name Description
X4:11 24VDC or L 24VDC , 110VAC or 240VAC
X4:10 GND or N 0VDC or Neutral
—

Terminal block X4 -Power Supply
Depending on the selected product type,
the power supply may be 24Vdc, 110Vac or
240Vac . Regardless of the voltage type, the
power supply should always be supplied
from an uninterrupted and reliable supply
source to ensure the operation reliability of
the device.
Power supply inputs are not phase re-
stricted which means in a 3 phase AC
power supply, any phase may be
wired to the inputs in any phase se-
quence.
03 . INSTALLATION AND WIRING 19

ABB M10 Series Specifications

General

Brand	ABB
Model	M10 Series
Category	Controller
Language	English
