Functionality of maintenance functions is based
on the parameters given by user. Functions
operate independently so that maintenance
functions can be active and alarms can be given
at the same time.
Number of starts
M10x counts number of starts. For each operation
cycle, M10x updates the number of operating
cycles in a memory map. When the start number
alarm level is exceeded, M10x issues an alarm.
Motor running time
M10x counts motors running hours. When the
running hours limit is crossed, M10x issues a
“running time” alarm.
Insertion cycles supervision
M10x gets the value of insertion cycles via
counting control power cycles. When times of
Insertion cycles exceeds alarm level, M10x issues
an alarm.
M10x records operation and events to assist in
trouble shooting and reporting.
Number of trips
M10x counts number of trips and updates them in
a memory map.
Parameter change counter
M10x counts times of parameter change and
updates them in a memory map.
SOE
M102 provides sequence of event recorder data
for up to 256 events with time stamp.
M102 has an internal clock which pro-
vides a time stamp during event
recording. To ensure a correct time
stamping, the internal clock shall be
set correctly before operation starts.
There are three methods to set the
clock- 1) Manually set the time via
MD21 panel; 2) Synchronize the time
using MCUSetup software; 3) Syn-
chronize the time through
communication network.
In case of M10x-TCP, time synchroniz-
ing is expected from SNTP server to
EM01 interface before further broad-
casting to M10x.
Maintenance and reporting functions
M10x monitors motor and motor starter service
condition to assist users to schedule service and
maintenance of the equipment.
07.CO N FI G U R A B L E INPUTS AND OUTPUTS 71
