•Configurable inputs type definition
Trigger mode Contactor type Function Description
Edge triggering NO, NC Start1 If the input status is different
than the setting, the function will
be active.
Start2
Stop*
Trip reset
PLC control1
PLC control2
Level triggering NO, NC Process interlock1 If the input status is the same as
the setting, the function will be
active.
Emergency stop If the input status is different
than the setting, the function will
be active.
Torque switch
Process interlock2
MD control
Test switch
External trip
Stop *
TOL Bypass
NOP Only detects the input status.
—
* Options of edge trigger type or level trigger type are available for 'stop' command.
Configurable outputs
In addition to three contactor control relays, there
are another two sets of configurable output re-
lays available in M102 model. As for M101 product
type, two sets of contactor control relays and one
set of configurable output relay are provided.
Similar as for configurable digital inputs, a wide
range of functions are available to be configured
to any of the digital outputs.
The contact status of the output re-
lays are not monitored by M10x
68 M OTO R CO NTRO L A N D PROTE C TI O N U N IT M10X USER G U I D E
