0 9. OPERATOR PANEL MDx 73
LED indicators
Four sets of LEDs are available on the front of the
MDx panel. LED1 is a single green color, while the
other three are dual colors. All four sets are
configurable with the functions listed below:
LEDs Configurable color Configurable functions
LED1 Ready(default), Running, Stop, Fault, Ready to Start,
Start1, Start2, DI0, DI1, DI2, DI3, DI4, DI5, DI6, DI7, DI8,
DI9iii, DI10iii, DI11iii, DI12iii
LED2 (default) Ready, Running, Stop, Fault, Ready to Start,
Start1(default), Start2, DI0, DI1, DI2, DI3, DI4, DI5, DI6, DI7,
DI8, DI9iii, DI10iii, DI11iii, DI12iii
LED3 (default) Ready, Running, Stop, Fault, Ready to Start, Start1,
Start2(default) , DI0, DI1, DI2, DI3, DI4, DI5, DI6,
DI7, DI8, DI9iii, DI10iii, DI11iii, DI12iii
LED4 (default) Ready, Running, Stop, Fault(default), Ready to Start,
Start1, Start2, DI0, DI1, DI2, DI3, DI4, DI5, DI6, DI7, DI8,
DI9iii, DI10iii, DI11iii, DI12iii
LED functions Meaning of the function
Ready M10x unit is powered up and ready for operation
Start1 Motor is running CW/N1
Start2 Motor is running CCW/N2
Running Motor is running CW/N1 or CCW/N2 or feeder is closed
Stop Motor is stopped or feeder is open
Ready to Start Motor is ready to start, ie, there is no active internal or external trip, motor is not under emergency
stop state (if defined) and Main Switch is ON (if defined) or TEST position (if defined)
Fault Motor is in fault
DIx iii The status of DIx
LED Status Explanation
On Assigned function is activated
Wink Alarm active or device is initializing
Off Inactive or off power *ii)
—
—
—
1. All LED lights wink at the same time
during changing parameters.
2. LED function is configurable through
MCUSetup software. LED label can be
customized and replaceable.
Remark: 1. DI9~DI12 are available for M10x 24VDC type only.
