ABB M2000 User Manual

8 Spare part / part list
8.3.6. Axis 3-4, 3HAC13063-1 (IRB 7600 - 150/3.5, - 325/3.1, -340/2.8, -400/2.55, -500/2.55)
3HAC022033-001 Revision: K444
© Copyright 2004-2011 ABB. All rights reserved.
Rot ac motor incl pinion, 3HAC024853-001
RV 125F-97,909 assembly, 3HAC17810-1
Cover ax 4 incl. sealing, 3HAC12640-1
102.1.20 1 2216261-18 Sealing 170x200x15
102.1.21 1 21522012-535 O-ring 169,3x5,7
102.1.22 1 3HAC022620-001 Spacer ring
102.1.23 1 3HAC11461-1 Sealing
102.1.24 1 3HAC17219-1 Thrust washer
102.1.25 1 9ABA135-45 Retaining ring, shaft
102.1.26 1 3HAC11928-1 Protective ring housing
102.1.27 1 3HAC17218-1 Set of shims
102.1.28 2 2522122-1 Magnetic plug G1/4"
102.1.29 2 3HAC16721-1 Magnetic plug
102.1.30 900
ml
3HAC032140-001 Lubricating oil:
Kyodo Yushi TMO 150
102.1.31 3,850
ml
3HAC032140-001 Lubricating oil:
Kyodo Yushi TMO 150
102.1.32 1 9ABA107-56 Parallel pin 10x20
102.1.33 2 3HAC10122-27 Friction washer
102.1.34 1 3HAB7116-1 Locking liquid
102.1.35 30 3HAB3537-1 Bearing grease
102.1.36 1 3HAC020486-001 Pinion Z3 / 4,5
102.1.37 1 3HAC020619-001 Set of shims Z3 / 4,5
102.1.38 9 3HAB7700-69 Hex socket head cap screw UNBRAKO 12.9
Gleitmo 610, M12x50
102.1.39 6 3HAB3409-86 Hex socket head cap screw Steel 12.9 Gleitmo
610, M16x60
102.1.40 2 21520441-1 Washer 13,5x18x1,5
Item Qty Art. number Description Note / Dimension
Item Qty Art. number Description Note
102.1.2.1 1 3HAC17484-2 Rotational ac motor M2
102.1.2.2 1 3HAC10122-17 Pinion RV 125F-97,909
102.1.2.3 1 21522012-430 O-ring
Item Qty Art. number Description Dimension
102.1.8.1 1 3HAC11384-1 RV 125F, i=97,909
102.1.8.2 1 3HAB3772-50 O-ring 196,52X2,62
102.1.8.3 1 3HAB3772-49 O-ring 189,3X3,1
Item Qty Art. number Description Note
102.1.9.1 1 3HAC11423-4 Cover axis 4 See following table.
102.1.9.2 1 3HAA1001-628 Sealing
Continued
Continues on next page
