8 Spare part / part list
8.3.6. Axis 3-4, 3HAC13063-1 (IRB 7600 - 150/3.5, - 325/3.1, -340/2.8, -400/2.55, -500/2.55)
4453HAC022033-001 Revision: K
© Copyright 2004-2011 ABB. All rights reserved.
Cover axis 4, 3HAC11423-4
Tube shaft 2,55, 3HAC10509-1
Axis 3, 3HAC13062-1
RV 700F incl. gear, 3HAC12641-1
Rot ac motor incl pinion, 3HAC14724-1
Item Qty Art. number Description Note
102.1.9.1.1 1 3HAC11423-1 Cover axis 4, machined
102.1.9.1.2 1 3HAC11423-3 Gasket cover axis 4
Item Qty Art. number Description Note
102.2.1 1 3HAC10509-2 Tube shaft 2,55, cast
102.2.2 1 3HAC1383-2 Protection Cover compl.
Item Qty Art. number Description Note / Dimension
102.3.1 1 3HAC10502-3 Axis 4 housing, mach.
102.3.2 1 3HAC12641-1 RV 700F incl. gear See following table.
102.3.3 20 3HAB7700-89 Hex socket head cap
screw
UNBRAKO 12.9
Gleitmo 610, M16x90
102.3.4 20 3HAC10264-1 Washer 17x30x3
102.3.5 1 3HAC14724-1 Rot ac motor incl pinion See following table.
102.3.6 4 3HAB3409-50 Hex socket head cap
screw
Steel 12.9 Gleitmo
610, M10x40
102.3.7 4 3HAB4233-1 Washer
102.3.8 1 3HAC16721-1 Magnetic plug
102.3.9 4,200 ml 3HAC032140-001 Lubricating oil:
Kyodo Yushi TMO150
102.3.10 1 9ABA142-92 Spring pin, slotted 10x30
Item Qty Art. number Description Note
102.3.2.1 1 3HAC17272-1 RV 700F-269,21 assembly
102.3.2.2 1 3HAC11636-1 Gear Z2 /2.3
Item Qty Art. number Description Note
102.3.5.1 1 3HAC17484-1 Rotational ac motor M1
102.3.5.2 1 3HAC11632-1 Pinion Z1 /2.3
102.3.5.3 1 21522012-430 O-ring
Continued
