1SDH002031A1002 ECN000092998 Rev. B SACE Tmax XT2 – XT4 | 128
System Interface
The document 1SDH002031A1101, in .zip format, is available in the ABB library in order to
ensure that the Ekip Com communication modules are used correctly; the file contains:
Document
Description
1SDH002031A1101.pdf
Guidelines with details for commissioning the communication
modules, with reference to protocols and to support documents
1SDH002031A1101.xlsx
Table with references of all the registers for the parameters, the
controls, the measurements, etc
The zip file contains the files for supplementing Ekip Touch in the communication networks that
are available with the specific Ekip Com module and an IMPORTANT file with notes on the use
of the files:
File
Ekip Com Protocol/Module
ABBS0E7F.gsd + EkiDPB.bmp
File .gsd and picture for configuring Ekip Com
Profibus DP
Ekip_COM_EtherNetIP_M4_v03_06.eds
File .eds for configuring Ekip Com EtherNet/IP™
Ekip_COM_DeviceNet_v02_08.eds
File .eds for configuring Ekip Com DeviceNet™
ABBEC0304_Ed1.icd
ABBEC0304_Ed2.icd
File .icd for configuring Ekip Com IEC 61850
GSDML-V2.3-ABB S.p.A.-Ekip Com
Profinet-20180823.xml
File .xml for configuring Ekip Com Profinet
NOTES:
 the file are also valid for the respective Redundant versions
 see the firmware version of the module to choose the correct configuration file
