1SDH002031A1002 ECN000092998 Rev. B SACE Tmax XT2 – XT4 | 96
Measurements
26 - Standard Measure
List
Standard measurements are:
Name
Description
Page
Real-time currents
Real-time measurements of phase currents
96
Events
List of events, status changes, alarms, recorded by the Trip
unit
97
Openings
List of trips (TRIP) for current protections
97
Min-Max
measurements
Log of minimum and maximum currents, recorded with
adjustable interval
98
Maintenance
CB status: contact wear and last maintenance
99
Counter operations
Number of mechanical and electrical operations
99
Real-time
currents
The real-time currents, available on the Main page and the Summary pages, are the real-time
measurements of phase and ground fault currents expressed in effective value. The
measurement range and the performance depend on the rated current defined by the rated size
of the Trip unit:
Measurement
Measurement range
(min-max)
Normal operating
range
Accuracy of
detected value
(1)
Phase currents
0.03 .. 64 In
0.2 .. 1.2 In
1%
(3)
Ground fault
current
(2)
0.08 .. 64 In
0.2 .. 1.2 In
2%
(3)
NOTES:
(1) Accuracy referring to normal operating ranges according to IEC 61557-12
(2) Available with LSIG versions
(3) Accuracy referring to Ekip Touch and Ekip Touch Measuring without Class 1
Power & Energy Metering package. If the Class 1 Power & Energy Metering
package is present, and for all other trip unit models, check the performance
shown on page 103
Special representations
Type of
measurement
Measurement <
min value
Measurement >
max value
Display: "_ _ _" (not
available) for
Phase currents
ground fault currents
. . . .
> [64 In]
Sensors disconnected
