1SDH002031A1002 ECN000092998 Rev. B SACE Tmax XT2 – XT4 | 150
Remote
configurations
From the service connector (via Ekip Connect) or with communication by system bus it is possible
to access additional parameters:
Parameter
Description
Default
Enable IEEE 1558
Permits the IEEE 1588 protocol for distributing the clock
and synchronization signal to be enabled
(NOTE)
OFF
IEEE 1588 Master
Enables the module to be set as a master in the network
segment to which it belongs (synchronization clock)
OFF
IEEE 1588 Delay
mechanism
Enables the data exchange mode between module and
master, between Peer-to-Peer and End-to-End to be
chosen
End-to-
End
Enable client SNTP
Permits enabling of SNTP distribution protocol of the
clock and synchronization signal
(NOTE)
OFF
SNTP Server Address
Enables the network server to be set that supplies SNTP
0.0.0.0
Time zone
Defines the time zone to be used for synchronism
+00:00
Daylight Saving Time
Enables it to be selected whether there is daylight
saving time(ON) or not (OFF) in the country to which the
synchronization time refers.
OFF
NOTE: Enable IEEE 1558 and Enable SNTP client must not be enabled simultaneously
Remote
information
From the service connector (via Ekip Connect) or with a system bus communication, additional
information can be accessed:
Information
Description
HW and Boot version
general module information
Flash CRC status and result
information on the correctness of the SW in the module
Ekip Link status
Signals connection errors of the Ethernet cable
SNTP Server Error
Communication error with the SNTP server
SNTP Server Synchronisation
Synchronism status with SNTP server
IEEE 1558 status
Valid with IEEE 1588 Master = ON, communicates the
presence (Slave or PTP Master Active) or absence (PTP
Master but Passive) of a higher level master
