1SDH002031A1002 ECN000092998 Rev. B SACE Tmax XT2 – XT4 | 199
Remote Link
configurations
With regard to the Link functions, additional parameters are available:
Parameter
Description
Default
Link Actor (1-15)
IP address of each actor (from 1 to 15)
0.0.0.0
Remote programmable
status (A-D)
Configuration parameters of the programmable states:
 Actor selection (actor from 1 to 15) which activates
the programmable status
 Event of the actor that determines the change of the
programmable status
Actor 1
Nobody
Status Word (A-D)
Word configuration parameters:
 actor selection (actor from 1 to 15) from which the
status word is taken
 selection of the word taken
Nobody
1 global
Diagnosis
Enable (passive diagnostics) or disable (no diagnostics)
the wired selectivity diagnostics
No
diagnostics
Diagnostic timeout check
Diagnostics check interval, if active, select from 30 s, 1
min, 10 min, 60 min
30 seconds
Zone selectivity type
Hardware selectivity configuration (HW only) or
hardware and logical (Mixed)
HW only
Repeat Configuration Mask
Interactive mask for selecting the selectivity to be
forwarded to the higher levels (even if not active on the
programmed device)
0x0000
Remote
information
From the service connector (via Ekip Connect) or with system bus communication it is also
possible to access additional information.
Information
Description
HW and Boot version
General module information
Flash CRC status and result
Information on the correctness of the SW on the module
Ekip Link Status
Reports connection errors of the Ethernet cable
SNTP Server Error
Communication error with the SNTP server
SNTP Server Synchronization
Synchronization status with the SNTP server
IEEE 1558 status
Valid with Master IEEE 1588 = ON, communicates the presence (Slave
or PTP Master Active) or absence (PTP Master but Passive) of a higher
level master
Remote Link
information
With regard to the Link functions, additional parameters are available:
Information
Description
Line Congruency detection
Information related to the status and inconsistencies of the HW
and logical selectivity (status and type of non-congruent
selectivity)
Remote programmable states
State (true/false) of the A, B, C and D remote programmable
states
Remote programmable word status
Value of the A, B, C, D remote programmable words
Logical zone selectivity
Logical selectivity states (inputs and outputs)
