TPU2000/2000R Modbus/Modbus Plus Automation Guide
91
6 = Invalid Data
7 = Settings being edited elsewhere in unit or remote edit disabled
8 = A write to one setting group attempted while actively editing
another.
9 = Breaker State Invalid
10 = Data entered is below minimum value
11 = Data entered is above maximum allowed
12 = Data entered is out of step
13 = Internal Software Error
32 = Reference Type or File Number Invalid
33 = Too many registers for Modbus Protocol
40176 Control Mask If Write Error Unsigned Integer
Control Mask 1 Write Mask (MSW)
40177 Control Mask If Write Error Unsigned Integer
Control Mask 1 Write Mask (LSW)
40178 Control Mask If Write Error Unsigned Integer
Control Mask 2 Write Mask (MSW)
40179 Control Mask If Write Error Unsigned Integer
Control Mask 2 Write Mask (LSW)
Metering Values (35 Registers Defined)
Metering Values are defined Table 5-19. Various data types are associated with each element. All metering
values are reported in primary units and should reflect the status as shown on the TPU2000/2000R Front Panel
Interface, ECP or WinECP metering screens. Many or the quantities are scaled, such as operating current to
denote a decimal point when read. Operate Current 40257 should be divided by 800 to obtain the decimal point
which is visible when viewing the value from the front panel.
Table 5-19. TPU2000/TPU2000R Metering Values Table
Register
Address
Item Scale
Factor
Description
40257 Operate Current A 800 Unsigned 16 Bit
40258 Operate Current B 800 Unsigned 16 Bit
40259 Operate Current C 800 Unsigned 16 Bit
40260 Restraint Current A Winding 1 800 Unsigned 16 Bit
40261 Restraint Current B Winding 1 800 Unsigned 16 Bit
40262 Restraint Current C Winding 1 800 Unsigned 16 Bit
40263 Restraint Current A Winding 2 800 Unsigned 16 Bit
40264 Restraint Current-B Winding 2 800 Unsigned 16 Bit
40265 Restraint Current C Winding 2 800 Unsigned 16 Bit
40266 Restraint Current A Winding 3 800 Unsigned 16 Bit
40267 Restraint Current B Winding 3 800 Unsigned 16 Bit
40268 Restraint Current C Winding 3 800 Unsigned 16 Bit
40269 Restraint Angle-A Winding 1 1 Unsigned 16 Bit
40270 Restraint Angle-B Winding 1 1 Unsigned 16 Bit
40271 Restraint Angle-C Winding 1 1 Unsigned 16 Bit
40272 Restraint Angle-A Winding 2 1 Unsigned 16 Bit
40273 Restraint Angle-B Winding 2 1 Unsigned 16 Bit
40274 Restraint Angle-C Winding 2 1 Unsigned 16 Bit
40275 Restraint Angle-A Winding 3 1 Unsigned 16 Bit
40276 Restraint Angle-B Winding 3 1 Unsigned 16 Bit
40277 Restraint Angle-C Winding 3 1 Unsigned 16 Bit
40278 % Second Harmonic-A Winding 1 2 Unsigned High Order Byte LSB
40278 % Second Harmonic-B Winding 1 2 Unsigned Low Order Byte MSB
40279 % Second Harmonic-C Winding 1 2 Unsigned High Order Byte LSB
40279 % Fifth Harmonic-A Winding 1 2 Unsigned Low Order Byte MSB
