ABB TPU2000R User Manual

TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
94
Register
Address
Item Description
NOTE 1: Version XXX TPU Executive and Version 1.80 Modbus or greater. 3 Winding Version only
RMS Voltage/Angular/Real and Reactive Power/Energy Values Block (17 Registers
Defined)
In addition to the Current values, the Voltage and Power values are reported in the same format. One should
notice that reporting of Power Factor and Signed Power Factor differ in register assignment with respect to
whether the TPU is a 2 Winding Unit (Part Number 588R or 588V) or a 3 Winding Unit (588T or 588Q).
Table 5-21. TPU2000/TPU2000R Metering Values Table
Register
Address
Item Scale Factor Description
40513 Voltage VA 1 Unsigned High Order Word LSW
40514 Voltage VA 1 Unsigned Low Order Word MSW
40515 Voltage VB 1 Unsigned High Order Word LSW
40516 Voltage VB 1 Unsigned Low Order Word MSW
40517 Voltage VC 1 Unsigned High Order Word LSW
40518 Voltage VC 1 Unsigned Low Order Word MSW
40519 Voltage VA Angle 1 Unsigned 16 Bit
40520 Voltage VB Angle 1 Unsigned 16 Bit
40521 Voltage VC Angle 1 Unsigned 16 Bit
40522 Voltage Positive Sequence 1 Unsigned High Order Word LSW
40523 Voltage Positive Sequence 1 Unsigned Low Order Word MSW
40524 Voltage Negative Sequence 1 Unsigned High Order Word LSW
40525 Voltage Negative Sequence 1 Unsigned Low Order Word MSW
40526 Voltage Positive Sequence Angle 1 Unsigned 16 Bit
40527 Voltage Negative Sequence Angle 1 Unsigned 16 Bit
40528 KWatts A 1 Unsigned High Order Word LSW
40529 KWatts A 1 Unsigned Low Order Word MSW
40530 KWatts B 1 Unsigned High Order Word LSW
40531 KWatts B 1 Unsigned Low Order Word MSW
40532 KWatts C 1 Unsigned High Order Word LSW
40533 KWatts C 1 Unsigned Low Order Word MSW
40534 KVars A 1 Unsigned High Order Word LSW
40535 KVars A 1 Unsigned Low Order Word MSW
40536 KVars B 1 Unsigned High Order Word LSW
40537 KVars B 1 Unsigned Low Order Word MSW
40538 KVars C 1 Unsigned High Order Word LSW
40539 KVars C 1 Unsigned Low Order Word MSW
40540 KWatt Hours A 1 Unsigned High Order Word LSW
40541 KWatt Hours A 1 Unsigned Low Order Word MSW
40542 KWatt Hours B 1 Unsigned High Order Word LSW
40543 KWatt Hours B 1 Unsigned Low Order Word MSW
40544 KWatt Hours C 1 Unsigned High Order Word LSW
40545 KWatt Hours C 1 Unsigned Low Order Word MSW
