ABB TPU2000R User Manual

TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
196
Register
Address
Item Description
Bit 0: Neutral Tap Range Wdg1 (lsb)
(0 = 1-12 A, 1 = 0.2-2.4A)
Bit 1: Neutral Tap Range Wdg1
(0 = 1-12 A, 1 = 0.2-2.4A)
Bit 2: Neutral Tap Range Wdg1
(0 = 1-12 A, 1 = 0.2-2.4A)
Bit 3: Neutral Tap Range Wdg1
(0 = 1-12 A, 1 = 0.2-2.4A)
Bit 4: User Definable Curves
Bit 5: Reserved
Bit 6: Neutral Tap Range Wdg 3
(0 = 1-12 A, 1 = 0.2-2.4A)
Bit 7: Phase Tap Range Wdg3
(0 = 1-12 A, 1 = 0.2-2.4A)
Bit 8: MOCT’s on Wdg1
(1= None 0= MOCT Present)
Bit 9: MOCT’s on Wdg1
(1= None 0= MOCT Present)
Bit 10: Reserved
Bit 11: Reserved
Bit 12: Reserved
Bit 13: Reserved
Bit 14: Reserved
Bit 15: Reserved (msb) (leftmost bit)
If the Alternate Settings 1 command is selected (as per Section 5 in this document), the settings are configured as
follows in Table 5-67).
Table 5-67. 3 Winding Primary Settings Block
Register
Address
Item Description
63200 SPARE_1
63201 Execute Register
0 = No Action
1 = Update Registers
2 = Refresh Registers
U
U
n
n
s
s
i
i
g
g
n
n
e
e
d
d
1
1
6
6
B
B
i
i
t
t
s
s
63202 Access Password ASCII – 2 Characters Leftmost Digits
63203 Access Password ASCII – 2 Characters Rightmost Digits
63204 SPARE_2
63205 87T-3 Amp Unsigned Integer 16 Bits
2<=Range<=9 (X10)
0.4<=Range<=1.8 (X50)
63206 51P-3 Curve Select (TYPE I ) Unsigned 16 Bits
Range 0-12 (See Text Above)
63207 51P-3 Pickup Amps Unsigned 16 Bits
1<=Range<= 12 *10
0.2<=Range<=2.4 Amp * 50 (See Note)
63208 51P-3 Time Dial/Time Delay Unsigned 16 Bits
1<=Range <=10 (X20) Time Dial
0<=Range<=10 (X20) Time Delay
63209 50P-3 Curve Select Byte (TYPE II) Unsigned Integer 16 bits
0<=Range<=12 (See Text Above)
63210 50P-3 Pickup Amps Unsigned 16 Bits
0.5<=Range<= 20 *10
63211 50P-3 Time Dial/Time Delay Unsigned 16 Bits
