TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
88
Table 5-14. Unit Information Status Modbus Address Map Definition
Register
Address
Item Description
40132 Relay Configuration
Bit 0 Meter Winding Mode
Bit 1 Meter Winding Mode
Bit 2 PT Configuration
Bit 3 Var/HR Unit Meas.
Bit 4 Voltage Meas. Tech.
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved (Msb)
Unsigned Integer
0,0 = Winding 1, 0,1 = Winding 2
1,0 = Winding 3
0 = Wye: 1 = Delta
0 = k Whr/k Varh, 1= M Whr/M Vhr
0 = Line to Neutral 1 = Line to Line
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
40133 Catalog Number (MSW) ASCII – 2 Characters Leftmost Digits
40134 Catalog Number ASCII – 2 Characters
40135 Catalog Number ASCII – 2 Characters
40136 Catalog Number ASCII – 2 Characters
40137 Catalog Number ASCII – 2 Characters
40138 Catalog Number ASCII – 2 Characters
40139 Catalog Number ASCII – 2 Characters
40138 Catalog Number ASCII – 2 Characters
40139 Catalog Number ASCII – 2 Characters
40142 Catalog Number (LSW) ASCII – 2 Characters Rightmost Digits
40143 Main CPU Sw Version Number Unsigned 16 Bit – (Scale Factor 100)
40144 Analog DSP Sw Version Number Unsigned 16 Bit – (Scale Factor 10)
40145 Front Panel Controller Sw Version
Number
Unsigned 16 Bit – (Scale Factor 10)
40146 Communication Sw Version Number Unsigned 16 Bit – (Scale Factor 10)
40147 Unit Serial Number (MSW) Unsigned Long 32 Bit (Most Significant Word – 16 Bits)
40148 Unit Serial Number (LSW) Unsigned Long 32 Bit (Least Significant Word – 16 Bits)
40149 Unit Name (Most Significant Digits) ASCII – 2 Characters (Leftmost Digits)
40150 Unit Name ASCII – 2 Characters
40151 Unit Name ASCII – 2 Characters
40152 Unit Name ASCII – 2 Characters
40153 Unit Name ASCII – 2 Characters
40154 Unit Name ASCII – 2 Characters
40155 Unit Name ASCII – 2 Characters
40156 Unit Name ASCII – 2 Characters
40157 Unit Name (Least Significant Digits) ASCII – 2 Characters (Rightmost Digits)
Read Quick Status (3 Registers Defined)
CT and PT ratio configuration data is available. As standard, The CT ratio is to 1as is the Neutral and PT ratios
are to 1. Quick status registers are illustrated in Table 5-15.
