ABB TPU2000R User Manual

TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
110
Table 5-29. Physical Input Table (1 Register Defined)
Register Item Description
41170 FORCE PHYS IN
Bit 15 = Reserved
Bit 14 = Reserved
Bit 13 = Reserved
Bit 12 = Reserved
Bit 11 = Reserved
Bit 10 = Reserved
Bit 9 = Reserved
Bit 8 = IN 9
Bit 7 = IN 8
Bit 6 = IN 7
Bit 5 = IN 6
Bit 4 = IN 5
Bit 3 = IN 4
Bit 2 = IN 3
Bit 1 = IN 2
Bit 0 = IN 1
Unsigned Integer 16 Bits msb (rightmost bit)
(msb leftmost bit)
(lsb rightmost bit)
Table 5-30. Force Table Mapping
Register
Address
Item Description
41171 FORCE PHYS IN
Bit 15 = Reserved
Bit 14 = Reserved
Bit 13 = Reserved
Bit 12 = Reserved
Bit 11 = Reserved
Bit 10 = Reserved
Bit 9 = Reserved
Bit 8 = IN 9
Bit 7 = IN 8
Bit 6 = IN 7
Bit 5 = IN 6
Bit 4 = IN 5
Bit 3 = IN 4
Bit 2 = IN 3
Bit 1 = IN 2
Bit 0 = IN 1
Unsigned Integer 16 Bits – Physical Input Select Status
Reserved (msb leftmost bit)
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced
0 = Normal, 1 = Forced (lsb rightmost bit)
41172 FORCE PHYS IN
Bit 15 = Reserved
Bit 14 = Reserved
Bit 13 = Reserved
Bit 12 = Reserved
Bit 11 = Reserved
Bit 10 = Reserved
Bit 9 = Reserved
Bit 8 = IN 9
Bit 7 = IN 8
Bit 6 = IN 7
Bit 5 = IN 6
Bit 4 = IN 5
Bit 3 = IN 4
Bit 2 = IN 3
Bit 1 = IN 2
Unsigned Integer 16 Bits – Physical Input Bit State
Reserved (msb leftmost bit)
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed
0 = Open, 1 = Closed
