TPU2000/2000R Modbus/Modbus Plus Automation Guide
209
3 = 60
61438 LCD Contrast Adjust Unsigned Integer 16 Bits
0<=Range <= 63
61439 Relay Password ASCII – 2 Characters Leftmost Digits
61440 Relay Password ASCII – 2 Characters Rightmost Digits
61441 Test Password ASCII – 2 Characters Leftmost Digits
61442 Test Password ASCII – 2 Characters Rightmost Digits
61443 Meter Winding Mode Unsigned Integer
0 = Winding 1
1 = Winding 2
2 = Winding 3
61444 VT Configuration Unsigned Integer 16 Bits
0 = 69 V Wye
1 = 120V Wye
2 = 120V Delta
3 = 208 V Delta
61445 VT Ratio Unsigned Integer 16 Bits
1<=Range<=45000
The Configuration Files for the 3 Winding TPU2000R is as follows:
Table 5-73. TPU2000/2000R Configuration Setting Register Setting
Register
Address
Item Description
63584 SPARE_1
63585 Execute Register
0 = No Action
1 = Update Registers
2 = Refresh Registers
Unsigned 16 Bit
63586 Access Password ASCII – 2 Characters Leftmost Digits
63587 Access Password ASCII – 2 Characters Rightmost Digits
63588 SPARE_2
63589 Winding 3 Phase CT Ratio Unsigned Integer 16 Bits
1<=Range<=4000
63590 Winding 3 Neutral CT Ratio Unsigned Integer 16 Bits
1<=Range<=4000
63591 Winding 3 Ground CT Ratio Unsigned Integer 16 Bits
1<=Range<=4000
63592 Winding 3 CT Configuration Unsigned Integer 16 Bits
0 = Wye
1 = Delta, IA-IC
2 = Delta, IA- IB
63593 Winding Phase Comp – Windings
1-3
Unsigned Integer 16 Bits
0<=Range <=330 / 30
Counters
TPU2000/TPU2000R has the ability to count breaker operations in a variety of modes. The same registers can
be accessed via a Modbus Code 03 (Read Holding Registers). For 4X read access, refer to Table 22. The same
information can be read via the refresh register capability through Register 61922. To reset the Breaker
Counters, write the value of 0 to Registers 61536 through 61547.
Table 5-74 is common to both the 2 Winding and 3 Winding TPU2000R and TPU2000 (available in 2 Winding
Format Only). Table 5-74 is only available for configuration of the TPU2000R 3 Winding Relay.
Table 5-74. Counter Register Assignment
