Address Item Description
61930 ULO 2 Rightmost 2 Characters 2 Digit ASCII Characters
61931 ULO 2 Characters 2 Digit ASCII Characters
61932 ULO 2 Characters 2 Digit ASCII Characters
61933 ULO 2 Leftmost 2 Characters 2 Digit ASCII Characters
61934 ULO 3 Rightmost 2 Characters 2 Digit ASCII Characters
61935 ULO 3 Characters 2 Digit ASCII Characters
61936 ULO 3 Characters 2 Digit ASCII Characters
61937 ULO 3 Leftmost 2 Characters 2 Digit ASCII Characters
61938 ULO 4 Rightmost 2 Characters 2 Digit ASCII Characters
61939 ULO 4 Characters 2 Digit ASCII Characters
61940 ULO 4 Characters 2 Digit ASCII Characters
61941 ULO 4 Leftmost 2 Characters 2 Digit ASCII Characters
61942 ULO 5 Rightmost 2 Characters 2 Digit ASCII Characters
61943 ULO 5 Characters 2 Digit ASCII Characters
61944 ULO 5 Characters 2 Digit ASCII Characters
61945 ULO 5 Leftmost 2 Characters 2 Digit ASCII Characters
61946 ULO 6 Rightmost 2 Characters 2 Digit ASCII Characters
61947 ULO 6 Characters 2 Digit ASCII Characters
61948 ULO 6 Characters 2 Digit ASCII Characters
61949 ULO 6 Leftmost 2 Characters 2 Digit ASCII Characters
61950 ULO 7 Rightmost 2 Characters 2 Digit ASCII Characters
61951 ULO 7 Characters 2 Digit ASCII Characters
61952 ULO 7 Characters 2 Digit ASCII Characters
61953 ULO 7 Leftmost 2 Characters 2 Digit ASCII Characters
61954 ULO 8 Rightmost 2 Characters 2 Digit ASCII Characters
61955 ULO 8 Characters 2 Digit ASCII Characters
61956 ULO 8 Characters 2 Digit ASCII Characters
61957 ULO 8 Leftmost 2 Characters 2 Digit ASCII Characters
61958 ULO 9 Rightmost 2 Characters 2 Digit ASCII Characters
61959 ULO 9 Characters 2 Digit ASCII Characters
61960 ULO 9 Characters 2 Digit ASCII Characters
61961 ULO 9 Leftmost 2 Characters 2 Digit ASCII Characters
ULI Connection Settings and User Names
The TPU2000/TPU2000R has internal Soft Bits, which are used for logical boolean programming. Please
reference the IL bulletin for a more detailed explanation of the use of these bits. Table 5-79 describes the register
designation.
Registers 61926 through 61958 contain the 8 characters, which make up the ULO Name.
Table 5-79. ULI Table Map For Character Name Assignment
Address Item Description
62048 SPARE_1
62049 Execute Register
0 = No Action
1 = Update Registers
2 = Refresh Registers
Unsigned 16 Bits
62050 Access Password ASCII – 2 Characters Leftmost Digits
62051 Access Password ASCII – 2 Characters Rightmost Digits
62052 SPARE_2
62053 ULI 1 Rightmost 2 Characters 2 Digit ASCII Characters
62054 ULI 1 Characters 2 Digit ASCII Characters
62055 ULI 1 Characters 2 Digit ASCII Characters
