ABB TPU2000R User Manual

TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
66
Note Register
Address
Item Description
3 10058: Reserved Reserved
3 10059: Reserved Reserved
3 10060: Reserved Reserved
3 10061: Reserved Reserved
3 10062: Reserved Reserved
3 10063: Reserved Reserved
3 10064: Reserved Reserved
3 10065: 51P-3 Winding 3 Phase Time Overcurrent Control Enabled
3 10066: 51N-3 Winding 3 Neutral Time Overcurrent Control Enabled
3 10067: 50P-3 1
st
Winding 3 Phase Time Instantaneous Control Enabled
3 10068: 50N-3 1
st
Winding 3 Neutral Time Instantaneous Control Enabled
3 10069: 150P-3 2
nd
Winding 3 Phase Time Instantaneous Control Enabled
3 10070: 150N-3 2
nd
Winding 3 Neutral Time Instantaneous Control Enabled
3 10071: 46-3 Winding 3 Negative Sequence Control Enabled
3 10072: 51G Ground Time Overcurrent Control Enabled
3 10073: 50G Ground Time Instantaneous Control Enabled
3= 3 Winding TPU Only
Physical Inputs (16 Elements Defined)
Physical inputs are map-able for various functional inputs. Input status correlates to the state of the input seen at
the physical terminals of the TPU2000/2000R their status is available at the following addresses as illustrated in
Table 5-6.
Table 5-6. Physical Input Modbus Address Map Definition
Notes Re
g
ister Address Item Descri
p
tion
10257: Reserved Reserved
10258: Reserved Reserved
10259: Reserved Reserved
10260: Reserved Reserved
10261: Reserved Reserved
10262: Reserved Reserved
10263 Reserved Reserved
10264 IN9 Ph
y
sical In
p
ut 9
10265: IN8 Ph
y
sical In
p
ut 8
10266: IN7 Ph
y
sical In
p
ut 7
10267: IN6 Ph
y
sical In
p
ut 6
10268: IN5 Ph
y
sical In
p
ut 5
10269: IN4 Ph
y
sical In
p
ut 4
10270: IN3 Ph
y
sical In
p
ut 3
10271: IN2 Ph
y
sical In
p
ut 2
10272: IN1 Ph
y
sical In
p
ut 1
Momentary Change Detect Logical Inputs (68 Elements Defined 2 Winding TPU - 160
Elements Defined 3 Winding TPU)
Whereas the information presented in Tables 5-5 and 5-6 illustrate the real time status of the designated data
points, the status in Table 5-7 lists the data in Momentary Change Detect status. The momentary change detect
decoding follows the same philosophy as that presented in Section 5 for the 0X logical and physical data
presentation.
Table 5-7. Logical Input Status Momentary Change Detect Status
Notes Register
Address
Item Description
