TPU2000/2000R Modbus/Modbus Plus Automation Guide
89
Table 5-15. Quick Status Modbus Address Map Definition
Register Address Item Description
40158 Phase CT Ratio Unsigned 16 Bit
40159 Neutral Ratio Unsigned 16 Bit
40160 PT Ratio Unsigned 16 Bit
Power Fail Status Information (9 Registers Defined)
If the TPU2000 or TPU2000R loses power, the unit has the capability to sense power is being lost. During this
shutdown time, the unit stores the timestamp of power fail occurrence. The storage format is shown in Table 5-
16.
Table 5-16. Power Fail Table Register Definition
Address Item Description
40161 Power Fail Timestamp Year Unsigned Integer 16 Bit
1900<=Range<= 2100
40162 Power Fail Timestamp Month Unsigned Integer 16 Bit
1<=Range <=12
40163 Power Fail Timestamp Day Unsigned Integer 16 Bit
1<=Range<=31
40164 Power Fail Timestamp Hours Unsigned Integer 16 Bit
0<=Range<=23
40165 Power Fail Timestamp Minutes Unsigned Integer 16 Bit
0<=Range<=59
40166 Power Fail Timestamp Seconds Unsigned Integer 16 Bit
0<=Range<=59
40167 Power Fail Timestamp Hundreths of Seconds Unsigned Integer 16 Bit
0<=Range<99
40168 Power Fail Timestamp Fail Type Unsigned Integer 16 Bit
1 = DC
40169 Power Fail Timestamp Machine State Unsigned Integer 16 Bit
0 = Circuit Breaker Closed
1 = Picked Up
2 = Circuit Breaker Tripping
3 = Circuit Breaker Failed to Open
4 = Circuit Breaker Open
6 = Circuit Breaker Open
7 = Circuit Breaker Failed to Open
8 = Control Switch Trip Fail
9 = Circuit Breaker State Unknown
Fast Status (2 Registers Defined)
Fast Status is available for an operator interface to determine the device queried. The Division Code for the
TPU2000/2000R is 1A HEX. The product ID for the TPU2000/2000R is 0E HEX.
One should also notice that the reporting of a new operation record is reported here in word 40170 in bit position
9. The bit is reset whenever the word is accessed via a network read.
