Rockwell Automation Publication 1734-UM018D-EN-E - September 2017 13
Chapter
2
Install Your 1734 POINT I/O EtherNet/IP
Adapter
Overview
This chapter describes how to physically install the POINT I/O Series B
EtherNet/IP adapter; and how to connect the adapter to your EtherNet/IP
network. The only tools you require are a flat or Phillips head screwdriver and a
drill.
This chapter includes the following topics:
Topic Page
Mount the POINT I/O Adapter on a DIN Rail 14
Install POINT I/O Modules 15
Replace An Adapter 16
Wire a POINT I/O Adapter 17
Chapter Summary 18
ATTENTION: You must only use Series C and above POINT I/O modules
with POINT I/O Adapters. Series A or Series B POINT I/O modules do not
work with POINT I/O Adapters (does not apply to POINTGuard modules).
